KYOCERA AVX SMX55C105KAN240 High-Temperature MLCC Capacitors
The SMX series stacked MLCC capacitors operate reliably at high temperatures up to 200°C, ideal for demanding environments like downhole oil exploration, space, and aerospace electronics. They feature multilayer ceramic construction with high capacitance and voltage ratings, low ESR, and excellent high-frequency performance. These capacitors are suitable for DC filtering, motor drives, pulsed-current circuits, and low power electronics, providing high temperature stability, low leakage, and enhanced current handling capabilities, ensuring durability in harsh conditions. They employ high-temperature solder for reliable operation in extreme environments.
KYOCERA AVX SMX55C105KAN240 High-Temperature MLCC Capacitors Specifications:
- Temperature Coefficient: COG: +30 ppm/°C from -55°C to +200°C, VHT: ±15% from -55°C to +125°C
- Capacitance Test: 25°C, 1020.2 Vrms at 1 kHz, MIL-STD-202 Method 305
- Dissipation Factor: Max 0.15% at 25°C, 1.0 Vrms, 1 kHz for COG; Max 2.5% for VHT
- Insulation Resistance: 100K MΩ at 25°C, 10K MΩ at 125°C, 1K MΩ at 200°C
- Dielectric Withstanding Voltage: 2.5 times rated voltage for 50 seconds, 500 V units at 750 VDC
- Resistance To Solder Heat: 20 seconds per MIL-STD-202 Method 210
- Not RoHS compliant, suitable for high frequency, high power, low leakage applications
- Dimensions vary with style; typical maximum height from 0.120 to 0.650 inches, with capacitance options up to 220,000 pF
- Features high temperature stability, low ESR, excellent performance at high frequencies, and robust mechanical design for demanding environments.
Buy the AVX SMX55C105KAN240 – Reliable High-Temperature Power Supply Capacitors for Industrial Applications
Purchase AVX SMX series high-temperature ceramic capacitors easily online. Perfect for aerospace, downhole exploration, and high-frequency electronics, these capacitors provide superior performance in harsh environments. Designed to operate reliably at temperatures up to 200°C, featuring low ESR, high current handling, and excellent stability across wide temperature ranges. Whether for DC filtering, motor drives, or pulsed-current applications, these capacitors ensure long-lasting durability, consistent capacitance retention, and optimal performance. Order now and upgrade your high-temperature circuit design with confidence.
Get AVX SMX55C105KAN240 today—built for durability in extreme environments and high-frequency circuits.
Frequently Asked Questions
Where can I buy KYOCERA AVX SMX55C105KAN240?
You can click on the BUY or RFQ button to purchase SMX55C105KAN240 from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part SMX55C105KAN240?
You can download the SMX55C105KAN240 datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of SMX55C105KAN240?
KYOCERA AVX
