KYOCERA AVX TCJB475M035R0200 Conductive Polymer Capacitor
The product is a high-reliability conductive polymer solid electrolytic chip capacitor suitable for electronic applications requiring low ESR, high capacitance, and tolerance for reflow soldering up to 260°C. It features a compact design with a wide CV range from 0.47 to 470uF and voltage ratings between 2.5V and 125V. Ideal for power supplies, smartphones, tablets, LCD TVs, and RoHS-compliant devices, it offers benign failure modes, excellent stability, and RoHS compliance for environmentally conscious manufacturing.
KYOCERA AVX TCJB475M035R0200 Conductive Polymer Capacitor Specifications:
- Capacitance range: 0.47-470uF
- Rated Voltage: 2.5V-125V
- Temperature Range: -55°C to +125°C
- Peak reflow temperature: 260°C for 8x
- ESR: Very low, stability at high frequencies
- Size: 35.7 x 20.0 mm (approximate for typical case)
- Lead-Free: Yes
- RoHS Compliant: Yes
- Leakage Current: 0.1CV specification
- Endurance: 1% reliability per 1000 hours at 85°C
- Storage conditions: 125°C for 2000 hours, humidity stable
- Soldering: 3x260°C reflow peak, 10s max
- Application: Power supplies, smartphones, tablets, LCD TVs
- Case sizes: 19 available, case dimension details vary by size
- Packaging: Bulk and tape options available
Buy the AVX Series TCJ Capacitor: 470 Microfarad 125V Low ESR - PartNumber TCJB475M035R0200
Purchase your AVX Conductive Polymer Capacitor with 470 microfarad capacity and 125V rating now. This high-quality, RoHS compliant capacitor ensures low ESR and excellent stability for power supplies, smartphones, and LCD TVs. Backed by industry standards, it features a benignant failure mode, robust endurance at 85°C, and RoHS compliance for environmentally friendly products. Order online today to enhance your electronic designs with proven reliability, advanced temperature tolerance, and flexible case sizes for various device requirements.
Order your AVX Series TCJ Capacitor with 470 microfarad 125V low ESR today and give your electronic devices the reliable, industry-grade performance they deserve.
Frequently Asked Questions
Where can I buy KYOCERA AVX TCJB475M035R0200?
You can click on the BUY or RFQ button to purchase TCJB475M035R0200 from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part TCJB475M035R0200?
You can download the TCJB475M035R0200 datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of TCJB475M035R0200?
KYOCERA AVX
