KYOCERA AVX TCN4477M016R0100 Conductive Polymer Capacitor
The TCN4477M016R0100 is a high-energy, conductive polymer solid electrolytic chip capacitor designed for compact applications. It features high volumetric efficiency, low ESR, and wide temperature range stability from -55°C to +125°C. Suitable for power backup, mobile devices, and industrial alarms, it offers excellent reliability with minimal parametric shifts under recommended use. The capacitor's undertab layout allows for high-density PCB integration, quick reflow compatibility, and RoHS compliance, ensuring optimal performance in demanding electronic systems.
KYOCERA AVX TCN4477M016R0100 Conductive Polymer Capacitor Specifications:
- Capacitance Range: 4.7 µF to 1500 µF
- Capacitance Tolerance: +20%
- Leakage Current (DCL): 0.1CV
- Rated Voltage (Vp) at +85°C: 6.3V, 10V, 16V, 20V, 25V, 35V, 50V
- Surge Voltage: 8V, 13V, 21V, 26V, 33V, 46V, 65V
- Temperature Range: -55°C to +125°C
- Series impedance: 0.10/0.20/0.50 Ohms depending on capacitance
- Reliability: 1% per 1000 hours at 85°C, Vp, with series impedance of 0.10/0.20/0.50 Ohms
- Series Compatibility: RoHS, 3x reflow at 260°C, lead-free, undertab layout for high PCB density
- Maximum ESR: Varies with case size, typically within catalog limits, RMS current ratings provided
- Storage and operating conditions align with JEDEC J-STD-020 MSL level 1
Buy the Buy NX Conductive Polymer Capacitor Part Number TCN4477M016R0100 Online
Enhance your electronic assemblies with the NX Conductive Polymer Capacitor, TCN4477M016R0100. This capacitor provides high energy density, outstanding low ESR, and wide temperature stability from -55°C to +125°C. Perfect for mobile, industrial, and backup applications, it features high volumetric efficiency, RoHS compliance, and quick reflow compatibility at 260°C. Benefits include reliable performance, low parametric shifts under stress, and high PCB density. Purchase online now for fast delivery and superior system performance.
Order your NX SeriesT CN4477M016R0100 capacitor today and ensure your electronic projects benefit from high reliability and compact design.
Frequently Asked Questions
Where can I buy KYOCERA AVX TCN4477M016R0100?
You can click on the BUY or RFQ button to purchase TCN4477M016R0100 from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part TCN4477M016R0100?
You can download the TCN4477M016R0100 datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of TCN4477M016R0100?
KYOCERA AVX
