KYOCERA AVX TCSE477M006CRSZ0723E Polymer Electrolytic Capacitor
This polymer solid electrolytic capacitor offers long operational life with high stability, low ESR, and excellent frequency retention. Designed for DC/DC converters, telecommunications, industrial, and avionics applications, it features a robust construction optimized for reliability, humidity resistance, and reflow compatibility up to 260°C. With ratings up to 1000 µF capacitance and voltages of 4V, 10V, and 25V, it ensures dependable performance under extreme environmental conditions, making it suitable for demanding electronic and power systems requiring high reliability and thermal stability.
KYOCERA AVX TCSE477M006CRSZ0723E Polymer Electrolytic Capacitor Specifications:
- Capacitance Range: 33 µF to 1000 µF
- Rated Voltage: 4V, 10V, 25V
- Capacitance Tolerance: +20%
- Temperature Range: -55°C to +125°C
- Leakage Current DCL: 0.1CV
- Reliability: 0.5% per 1000 hours at 85°C
- Termination Finish: Sn Plating or SnPb (Non RoHS)
- Surge Test Level: Optional
- RoHS Compliant: Yes
- Shock and Vibration: MIL-STD-202 compliant
- Power Dissipation: Low ESR, high frequency retention
- Reflow Compatibility: Up to 260°C
- Humidity Resistance: 85°C/85%RH for 500 hours
Buy the Buy AVX Polymer Electrolytic Capacitor Part Number TCSE477M006CRSZ0723E Online
Purchase the AVX polymer electrolytic capacitor TCSE477M006CRSZ0723E online now for reliable, high-performance power solutions. This capacitor features low ESR, excellent frequency stability, and robust construction, making it ideal for critical applications like telecommunications, industrial equipment, and avionics. Its wide temperature range, resistance to humidity, and reflow compatibility ensure dependable operation in demanding environments. With a capacitance of 6µF at 25V, it provides long-lasting, stable performance, simplifying your assembly process and fulfilling your high-reliability project needs. Buy online today and guarantee power efficiency and durability!
Order your AVX SeriesTCSE477M006CRSZ0723E high stability capacitor today and ensure long-lasting, dependable power performance for your advanced electronics.
Frequently Asked Questions
Where can I buy KYOCERA AVX TCSE477M006CRSZ0723E?
You can click on the BUY or RFQ button to purchase TCSE477M006CRSZ0723E from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part TCSE477M006CRSZ0723E?
You can download the TCSE477M006CRSZ0723E datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of TCSE477M006CRSZ0723E?
KYOCERA AVX
