KYOCERA AVX TPSD336K035T0200V Tantalum Capacitor
This tantalum capacitor features a capacitance of 33 uF rated at 35V DC, designed for automotive low ESR applications. It operates within -55°C to +125°C temperature range, meeting ROHS and AEC-Q200 standards. The low dissipation factor of 6% at 120Hz and ESR max of 0.2 Ohm at 100kHz ensure excellent performance in high-reliability electronic circuits. Its compact case dimensions, lead-free construction, and surge current testing make it ideal for demanding automotive and industrial applications, with moisture sensitivity at level 3.
KYOCERA AVX TPSD336K035T0200V Tantalum Capacitor Specifications:
- Capacitance: 33 uF
- Rated Voltage DC: 35V
- Category Voltage DC: 23V
- Surge Voltage: 46V
- Temperature Range: -55°C to +125°C
- Leakage Current Max: 11.6 pA at Va
- Dissipation Factor Max: 6% at 120Hz
- ESR Max: 0.2 Ohm at 100kHz
- Weight: 290 mg
- Moisture Sensitivity Level: 3
- Reflow Standard: J-STD-020
- Meets AEC-Q200, RoHS, Lead-Free
- Ripple Current @ 100kHz: 866 mA at 25°C
- Case Dimensions: 7.3 x 4.3 mm (L x W), Height: 2.9 mm
- Polarity: Positive terminal marked on the case
Buy the Buy AVX Tantalum Capacitor Part Number TPSD336K035T0200V Online
Order the AVX Tantalum Capacitor TPSD336K035T0200V now and benefit from its low ESR, high temperature stability, and RoHS compliance. Perfect for automotive and industrial electronics demanding reliable, high-performance power filtering. Its compact size and surge current capability make it suitable for demanding environmental conditions. Take advantage of easy online purchasing, fast shipping, and dedicated support. Ensure your circuit’s durability with this high-quality, lead-free tantalum capacitor designed for longevity and stability in critical applications.
Get AVX TPSD336K035T0200V today—designed for automotive reliability and low ESR performance in high-demand circuits.
Frequently Asked Questions
Where can I buy KYOCERA AVX TPSD336K035T0200V?
You can click on the BUY or RFQ button to purchase TPSD336K035T0200V from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part TPSD336K035T0200V?
You can download the TPSD336K035T0200V datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of TPSD336K035T0200V?
KYOCERA AVX
