KYOCERA AVX TPSE227K016T0100V Tantalum Capacitor
This low ESR tantalum capacitor features 220 microfarads capacitance at 120Hz, rated voltage of 16V DC, and operates within -55°C to +125°C temperature range. It is RoHS compliant, meets AEC-Q200 standards, and is reflow solderable according to J-STD-020. Designed for automotive and industrial applications, it offers low leakage current, high surge current capability, and is lead-free. The capacitor's compact case dimensions and high reliability make it ideal for power supply filtering, decoupling, and energy storage in demanding environments.
KYOCERA AVX TPSE227K016T0100V Tantalum Capacitor Specifications:
- Capacitance: 220 μF @ 120Hz
- Capacitance Tolerance: K = 410%; M = +20%
- Rated Voltage DC: 16V at < 85°C
- Category Voltage DC: 10V at < 125°C
- Surge Voltage: 20V at < 85°C, 13V at 125°C
- Temperature Range: -55°C to +125°C
- Leakage Current Max: 35.2 μA @ rated V
- Dissipation Factor Max: 10% @ 120Hz
- ESR Max: 0.1 Ohm @ 100kHz
- Approximate Weight: 512 mg
- Moisture Sensitivity Level: MSL 3
- Reflow Standard: J-STD-020
- Standards: RoHS, AEC-Q200 compliant
- Surge Test: 100% tested for surge current
- Ripple Current @ 100kHz: 1285 mA at 25°C, 1156 mA at 85°C, 514 mA at 125°C
- Ripple Voltage @ 100kHz: 128 mV at 25°C, 116 mV at 85°C, 51 mV at 125°C
Buy the AVX TPSE227K016T0100V – Reliable Capacitor for Industrial Applications
Enhance your electronic designs with this high-quality tantalum capacitor designed for automotive and industrial applications. Featuring 220 microfarads capacity at 16V rating, it ensures reliable power filtering and energy storage. Its low ESR and high surge current capability hold up under extreme conditions, while RoHS compliance and adherence to AEC-Q200 standards guarantee safety and durability. Compact and lightweight at 512 mg, this capacitor is ideal for demanding environments, offering excellent performance across a temperature range of -55°C to +125°C. Purchase online today for long-lasting reliability.
Get AVX TPSE227K016T0100V today—built for automotive and industrial power stability.
Frequently Asked Questions
Where can I buy KYOCERA AVX TPSE227K016T0100V?
You can click on the BUY or RFQ button to purchase TPSE227K016T0100V from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part TPSE227K016T0100V?
You can download the TPSE227K016T0100V datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of TPSE227K016T0100V?
KYOCERA AVX
