Littelfuse 0299080TXN Blade Fuse
This MAXI blade fuse rated for 32V is designed for automotive and safety applications, offering reliable performance with diffusion pill technology for predictable time delay characteristics. It features Ag-plated zinc alloy terminals ensuring durability and low heat dissipation, with a maximum interrupting rating of 1000A at 32V DC. Suitable for critical electrical systems, it complies with SAE J 1888 and ISO 8820-3:2002(E) standards, making it ideal for vehicle and industrial applications requiring high current protection and dependable safety performance.
Littelfuse 0299080TXN Blade Fuse Specifications:
- Voltage Rating: 32 V DC
- Interrupting Rating: 1000A at 32 V DC
- Operating Temperature Range: -40°C to +125°C
- Terminal Material: Silver plated zinc alloy
- Housing Material: PAGE (Polytetrafluoroethylene-based)
- Standards Compliance: SAE J 1888, ISO 8820-3:2002(E)
- Dimensions: Length approximately 20.21 mm, width 8.85 mm, height 21.59 mm
- Temperature Rerating Curve: 100% rated current at -40°C, with variations at other temperatures
- Time-Current Characteristics: Blowing times vary from milliseconds to several minutes depending on current
- Application: Automotive, safety, industrial electrical systems
Buy the Littelfuse Series MAXI Blade Fuse: 0299080TXN
Secure your electrical systems with the reliable 32V MAXI blade fuse from Littelfuse. Designed for automotive and safety applications, it features diffusion pill technology for predictable delay times and low heat dissipation. With silver-plated zinc alloy terminals, it offers high durability, a 1000A interrupting rating, and compliance with industry standards including SAE J 1888 and ISO 8820-3. Ideal for critical circuitry, this fuse guarantees safety, performance, and extended service life for vehicles and industrial equipment. Shop online now for fast delivery and peace of mind.
Order your Littelfuse Series MAXI blade fuse 0299080TXN today and ensure your vehicle's safety and electrical system reliability.
Frequently Asked Questions
Where can I buy Littelfuse 0299080TXN?
You can click on the BUY or RFQ button to purchase 0299080TXN from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 0299080TXN?
You can download the 0299080TXN datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 0299080TXN?
Littelfuse
