Littelfuse 0451001MRL Fast-Acting Surface Mount Fuse
The Littelfuse Nano[2] SMF Fuse is a compact surface mount fuse ideal for secondary side over-current protection in a variety of applications. Its wire-in-air design and small size make it suitable for PCB integration. Key features include fast-acting performance, low temperature derating, RoHS compliance, halogen-free construction, a wide operating temperature range, and current ratings from 62mA to 15A. Common applications include notebook PCs, telecom systems, LCD/PDP TVs, wireless basestations, and power supplies.
Littelfuse 0451001MRL Fast-Acting Surface Mount Fuse Specifications:
- Agency Approvals: E10480 (6.3A - 15A), LR29862 (62mA - 15A), PS NBK030205-E10480B (1A - 5A), E NBK101105-E184655 (6.3A - 10A), E10480 (62mA - 5A)
- Ampere Rating: 62mA - 15A
- Opening Time: 1/16 –15 (4 hours), 1/16 –10 (5 sec), 12 –15 (20 sec)
- % of Ampere Rating: 100%, 1/16, 200%
- Body Material: Ceramic
- Termination Material: Gold-Plated Caps / Sn-dipped Silver Plated
- Operating Temperature: -55°C to 125°C
- Moisture Sensitivity Level: Level 1, J-STD-020C
- Insulation Resistance: 10,000 ohms minimum
- Thermal Shock: MIL-STD-202, Method 107
- Mechanical Shock: MIL-STD-202, Method 201
- Vibration: MIL-STD-202, Method 213
- Salt Spray: MIL-STD-202, Method 101
- Resistance to Soldering Heat: MIL-STD-202, Method 210
Buy the 0451001.MRL LITTELFUSE Fast-Acting Surface Mount Fuse | myMectronic
Purchase the Littelfuse 0451001.MRL fuse securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Littelfuse 0451001MRL?
You can click on the BUY or RFQ button to purchase 0451001MRL from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 0451001MRL?
You can download the 0451001MRL datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 0451001MRL?
Littelfuse
