Littelfuse 0451015MRL Surface Mount Fuse
The 0451015MRL is a compact, fast-acting surface mount fuse rated at 15A and 125VAC, designed for PCB secondary circuit protection. Made with a ceramic body and gold-plated caps, it features tin-lead alloy terminations, suitable for high-reliability applications with low temperature de-rating. Operating from -55°C to 125°C, it has a nominal resistance of approximately 0.0037 ohms. Its small size, halogen-free construction, and RoHS compliance make it ideal for safety, power management, communication, consumer electronics, automation, and industrial control systems.
Littelfuse 0451015MRL Surface Mount Fuse Specifications:
- Electrical Rating: 15A, 125VAC
- Body Material: Ceramic
- Cap Material: Gold over Nickel plated (RoHS compliant options available)
- Terminations: Tin-Lead Alloy
- Resistance: Approximately 0.0037 ohms at cold conditions
- Temperature Range: -55°C to 125°C
- Interrupting Ratings: 50 A at 125 VAC/VDC, 300 A at 32 VDC, 35 A at 125 VAC
- Soldering Parameters: Wave solder at 260°C for 10 seconds, reflow at 260°C for 30 seconds
- Solderability: Compliant with MIL-STD-202, Method 208
- Packaging: 12mm Tape and Reel, 1000 pieces per reel, optional RoHS 'L' suffix for compliance
Buy the Littelfuse Series 451 15A Surface Mount Fuse: 0451015MRL
Secure your electronic projects with the Littelfuse 0451015MRL surface mount fuse. Rated at 15A and 125VAC, this ceramic-bodied, gold-cap fuse offers fast-acting protection. It's ideal for PCB applications requiring high reliability, low temperature de-rating, and RoHS compliance. The small size ensures easy integration into various systems, including consumer electronics, industrial controls, power management, and communication devices. Trust in proven durability with a cold resistance of 0.0037 ohms and operation from -55°C to 125°C, ensuring safe and efficient circuit protection.
Buy Littelfuse 0451015MRL now and experience unmatched reliability and performance for PCB circuit protection in industrial and electronics applications.
