Littelfuse 0452002NRL Nano² Fuse
The Nano² series 2A time-delay anti-surge fuse features a ceramic body and gold-plated caps, designed for surface mounting. Its enhanced inrush current withstand capability prevents nuisance tripping, ideal for sensitive electronic circuits such as computers, portable devices, industrial equipment, and wireless communication systems. Operating within a temperature range of -55°C to 125°C, the fuse boasts a 300A interrupting rating at 32VDC. Its halogen-free construction ensures safety and environmental compliance. This compact fuse combines reliability, effective surge protection, and easy surface mounting, making it suitable for power management and networking applications.
Littelfuse 0452002NRL Nano² Fuse Specifications:
- Current Rating: 2A
- Voltage Rating: 125VAC/DC
- Interrupting Rating: 300A at 32VDC
- Body Material: Ceramic
- Cap Material: Gold-plated
- Temperature Range: -55°C to 125°C
- RoHS Compliant: Yes
- Halogen Free: Yes
- Mounting Type: Surface mount
- Operating Environment: Sensitive electronic devices, power supplies, industrial equipment
- Soldering Temperature: Follow reflow parameters: max 260°C, peak at 260°C for 3s
- Soldering Method: Reflow, wave soldering compatible within specified parameters
- Certification: UL Recognized, RoHS compliant
Buy the Littelfuse Series Nano² 452 Time-Delay Fuse: 0452002NRL
Purchase the Littelfuse Nano² series 2A surface-mount time-delay fuse online for optimal surge protection. Designed with a ceramic body and gold-plated caps, it offers high current handling and operates within -55°C to 125°C. Suitable for electronic devices, industrial applications, power supplies, and networking equipment, this RoHS-compliant, halogen-free fuse ensures safety and durability. Easy to install, it provides dependable, long-lasting surge suppression. Order now to enhance your device’s durability and safeguard sensitive circuits with this high-performance surface-mount fuse designed for modern electronic systems.
Get Littelfuse Nano² 452 series 2A fuse today—built for reliable surge protection in sensitive electronics and industrial systems.
