Littelfuse 0473005YRT1L Slo-Blo Fuse
The Littelfuse PICO II Slo-Blo fuse is a reliable and versatile fuse designed to provide time-delay performance while maintaining proven reliability. It's engineered with enhanced inrush withstand capabilities and is manufactured to be halogen-free and RoHS compliant, ensuring environmental responsibility. This fuse is ideal for applications such as flat-panel display TVs, medical equipment, LCD monitors, industrial equipment, and lighting systems. Its compact size, wide operating temperature range, and broad range of current ratings (0.375A - 7A) make it a suitable choice for various electronic devices. The fuse is available in different packaging options, including reel, ammo pack, and loose pack, to meet diverse manufacturing needs.
Littelfuse 0473005YRT1L Slo-Blo Fuse Specifications:
- Ampere Range: 0.375A - 7A
- Opening Time (100% Rating): 4 Hours (Min.)
- Opening Time (200% Rating): 1 Sec. (Min.); 60 Sec. (Max.)
- Opening Time (300% Rating): 0.2 Sec. (Min.); 3 Sec. (Max.)
- Opening Time (800% Rating): 0.02 Sec. (Min.); 0.1 Sec. (Max.)
- Max Voltage: 125V
- Interrupting Rating: Varies by Ampere Rating (see table)
- Resistance: Varies by Ampere Rating (see table)
- Operating Temperature: –55ºC to +125ºC
- Lead Pull Force: 7 lbs (Min.)
- Insulation Resistance: 10,000 ohms minimum at 100 volts
- Resistance to Soldering Heat: 20 sec at 260ºC
- Thermal Shock: –65ºC to 125ºC
- Moisture Resistance: 90–98% RH, 65ºC
- Agency Approvals: E10480, 29862, PSE
- Materials: Solder Coated Copper wire leads
- Lead Length (T1): 52.4mm (2.062")
- Full Component Length: 62.7mm (2.468")
- Packaging Options: Reel, Ammo Pack, Loose Pack
Buy the 0473005.YRT1L Littelfuse Slo-Blo Fuse | myMectronic
Purchase the Littelfuse 0473005.YRT1L Slo-Blo Fuse securely online and ensure reliable protection for your electronic devices.
Buy Now
Frequently Asked Questions
Where can I buy Littelfuse 0473005YRT1L?
You can click on the BUY or RFQ button to purchase 0473005YRT1L from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 0473005YRT1L?
You can download the 0473005YRT1L datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 0473005YRT1L?
Littelfuse
