Littelfuse 0487016MXEP High-Energy Fast-Acting Fuse
The 487 Series is a 5x20mm fast-acting ceramic fuse rated for 420VAC and 420VDC, designed to protect high-energy applications including power supplies, inverters, and data center systems. It offers quick response times, with minimum trip times of 0.04 seconds at 20A, and is ideal for high-voltage DC grids and three-phase power. Constructed with a ceramic body, nickel-plated brass caps, and tin-plated copper leads, this fuse ensures reliable operation in demanding environments. RoHS compliant and lead-free, it features robust electrical and thermal ratings with easy installation in axial lead configurations.
Littelfuse 0487016MXEP High-Energy Fast-Acting Fuse Specifications:
- Body Material: Ceramic
- Cap Material: Nickel-plated Brass
- Lead Material: Tin-plated Copper
- Rated Voltage: 420VAC / 420VDC
- Current Ratings: 8A, 10A, 12.5A, 15A, 16A, 20A
- Trip Time: 0.04 sec. min. at 20A, 20 sec. max. at 20A
- Interrupting Rating: 750A@250VAC for 20A
- Temperature Range: -55°C to +125°C
- Length: 20mm, Diameter: 5mm
- RoHS compliant, Lead-Free
- Designed for high-energy applications including three-phase power supplies and telecom power systems
- Construction: Ceramic body with nickel-plated brass caps and tin-plated copper leads
Buy the Buy Littelfuse 487 Series Part Number 0487016MXEP Online
Purchase the Littelfuse 487 Series 5x20mm fast-acting fuse today online. Designed for high-energy applications, it features a ceramic body, quick trip times, and high voltage ratings. Ideal for power supplies, inverters, telecom systems, and data centers, this fuse provides reliable overload protection, with current ratings up to 20A and interrupting ratings of 750A at 250VAC. Its robust construction ensures long-term durability and safety in demanding electrical environments, offering an excellent choice for engineers and technicians improving system reliability.
Buy Littelfuse 487 Series 20A fast-acting fuse now and ensure reliable protection for your high-voltage power supplies and data center systems.
Frequently Asked Questions
Where can I buy Littelfuse 0487016MXEP?
You can click on the BUY or RFQ button to purchase 0487016MXEP from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 0487016MXEP?
You can download the 0487016MXEP datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 0487016MXEP?
Littelfuse
