Littelfuse 2920L20024DR Polyfuse Overcurrent Protector
The 2920L200/24DR Polyfuse resettable PTC provides reliable overcurrent protection for surface-mount applications in medium voltage environments. It features a compact, low-profile design, ideal for space-constrained electronic devices. With a hold current of 2A and trip current of 4A, it responds rapidly to fault conditions, preventing damage in computers, consumer electronics, and automotive systems. RoHS compliant and halogen-free, this device ensures safe, environmentally friendly installation. Perfect for protecting powered ethernet ports, control modules, and other critical components requiring dependable, resettable protection.
Littelfuse 2920L20024DR Polyfuse Overcurrent Protector Specifications:
- Package Type: Surface Mount, Low Profile
- Maximum Surface Temperature: 125°C
- Hold Current: 2A
- Trip Current: 4A
- Resistance (typical): 0.125Ω at 20°C
- Voltage Rating: 60V
- Temperature Rating: -40°C to +85°C
- RoHS Compliant, Halogen-free
- Size: Approximate dimensions 16.0mm x 7.50mm x 1.75mm
- Reflow Parameters: Max ramp-up rate 3°C/sec, peak temperature 260°C, Max duration 60-150 sec
- Application: Overcurrent protection in computers, automotive, telecom, and consumer electronics
- Certifications: UL Listed, RoHS compliant
- Operating Conditions: Suitable for environments up to 85°C ambient temperature
Buy the Littelfuse 2920L200/24DR – Reliable Overcurrent Protection for Industrial Applications
Purchase Littelfuse 2920L200/24DR today and ensure your electronic devices are safeguarded with high-performance, resettable overcurrent protection. Its compact design makes it ideal for space-constrained applications, providing rapid response to overcurrent faults in computers, automotive electronics, and telecom equipment. RoHS compliant and halogen-free, this device offers environmentally friendly protection while maintaining high reliability and durability. Order now and improve the safety and resilience of your critical components with this trusted Polyfuse solution.
Get Littelfuse 2920L200/24DR today—built for precision and long-lasting durability in electronic and automotive systems.
Frequently Asked Questions
Where can I buy Littelfuse 2920L20024DR?
You can click on the BUY or RFQ button to purchase 2920L20024DR from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 2920L20024DR?
You can download the 2920L20024DR datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 2920L20024DR?
Littelfuse
