Littelfuse 37011000000 TR5 Fuse
The 370 Series TR5 Fuse is a compact, fast-acting electronic fuse rated at 250V, designed for reliable circuit protection in industrial and consumer applications. It features a sub-miniature size, low internal resistance, and vibration resistance, making it ideal for power supplies and industrial controllers. Available in various current ratings from 0.040A to 6.3A, these lead-free, halogen-free fuses comply with RoHS and IEC standards, offering direct solder or plug-in options, ensuring efficient space utilization and high safety margins across demanding environments.
Littelfuse 37011000000 TR5 Fuse Specifications:
- Rated Voltage: 250V
- Type: Fast-Acting TR5 Fuse
- Series: 370
- Current Range: 0.040A to 6.3A
- Housing Material: Brown thermoplastic, UL 94-0
- Pin Material: Copper, tin-plated
- Operating Temperature: -40°C to +85°C
- Breaking Capacity: 50A at 250V
- Lead Configuration: Radial lead, short or long leads
- Soldering: Wave and iron soldering compatible at 260°C for <3s
- Compliance: RoHS, IEC 60127-3
- Dimensions: Compact size with standard PCB footprint
- Humidity Resistance: Up to 95% for 30 days
- Climatic Category: D8.5
- Packaging: Tape & Ammopack or bulk options
- Lead Pull Strength: 10 N
- Solder Iron Temperature: 350°C +/- 5°C
- Vibration Resistance: 10-60Hz, 0.75mm amplitude
Buy the Buy Littelfuse 370 Series TR5 Fuse Part Number 37011000000 Online
Secure your electronic circuits with the Littelfuse TR5 Fuse, a fast-acting, compact fuse rated at 250V with a broad current range from 0.040A to 6.3A. Designed for industrial power supplies and controllers, it features RoHS compliance, vibration resistance, and easy soldering options. Its reliable circuit protection safeguards equipment against overcurrent conditions in various settings. Purchase the Littelfuse TR5 Fuse online today for quick delivery, ensuring optimal circuit safety and performance in your critical systems.
Buy Littelfuse 370 Series TR5 Fuse now and experience unmatched reliability and high safety standards for industrial applications.
