Littelfuse MINISMDC010F2 Overcurrent Protection Device
The miniSMDC series offers surface mount overcurrent protection ideal for space-constrained applications requiring reliable, resettable safety devices. These PolySwitch protectors feature broad RoHS compliance, UL recognition, and IEC standards, delivering low resistance in a compact 1812 footprint. Designed for various industrial and electronic uses, they provide fast trip times and high surge capacity. Suitable for mobile electronics, batteries, automotive, and industrial controls, these PPTCs ensure overcurrent protection with excellent thermal and environmental stability, making them essential for modern electronic device safety and reliability.
Littelfuse MINISMDC010F2 Overcurrent Protection Device Specifications:
- Size: 1812 footprint
- Terminal Pad Material: 100% Matte Tin with Nickel Underplate
- Rated Voltage (Voc): 60V
- Hold Currents: Ranging from 0.10A to 4.13A depending on model
- Maximum Trip Current: up to 30A
- Resistance Change: 3% typical
- Temperature Rating: -40°C to +85°C
- Soldering Characteristics: ANSI/J-STD-002 Category 3, IEC 60068-2-20
- Storage Life: 60°C, 1000 hrs; Humidity Aging: 85°C, 1000 hrs
- Vibration and Thermal Shock Resistance
- Flammability Resistance: UL 94V-0
- Reliability: Recognized to UL 1434 and IEC 60730-1
Buy the Littelfuse MINISMDC – Reliable PPTC for Industrial Applications
Ensure the safety and reliability of your electronic systems by purchasing Littelfuse miniSMDC series PPTCs online. These surface-mount resettable devices provide quick response to overcurrent events, compliant with industry standards, and suited for space-constrained applications. With broad application compatibility including mobile electronics, batteries, automotive, and industrial controls, these PPTCs enhance device safety while simplifying installation. Buy directly from authorized online distributors and benefit from fast delivery, quality assurance, and technical support for your critical electronics projects.
Buy Littelfuse MINISMDC series PPTC devices now and ensure reliable overcurrent protection in your critical electronic and industrial systems.
Frequently Asked Questions
Where can I buy Littelfuse MINISMDC010F2?
You can click on the BUY or RFQ button to purchase MINISMDC010F2 from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part MINISMDC010F2?
You can download the MINISMDC010F2 datasheet or visit the Littelfuse website for support.
Who is the manufacturer of MINISMDC010F2?
Littelfuse
