Littelfuse PSR030FS0250Z High-Speed Semiconductor Fuse
Littelfuse PSR Series High-Speed Square Body Fuses are designed for protecting power semiconductor devices like IGBTs, SCRs, and diodes in power conversion equipment such as inverters, UPS, and soft starters. These fuses offer fast response, current limiting, and high cycle capability, making them ideal for sensitive electronic circuits demanding reliable, high-speed protection. They meet international certifications including UL, IEC, and CCC, with options for flush end mounting, visual or microswitch indication, and are suitable for a variety of industrial applications including electric vehicles, battery systems, and industrial drives.
Littelfuse PSR030FS0250Z High-Speed Semiconductor Fuse Specifications:
- Voltage Range AC: 550 V - 1300 V
- DC: 500 V - 1000 V
- Amperage Range: 40A-2000A
- Interrupting Range AC: 100 kA - 200 kA
- DC: 150 kA
- Time Constant: 10ms
- Material Body: Ceramic
- Contacts: Plated Brass
- Mounting: Flush-End Style
- Operating Temperature: -55°C to +125°C
- Certifications: UL Recognized, C-UR-US, IEC 60269-4, RoHS, REACH
- Electrical Ratings: Various, per amperage and voltage, model-specific
Buy the Littelfuse PSR – Reliable Semiconductor Protectors for Industrial Applications
Order Littelfuse PSR250 high-speed semiconductor fuse online today and secure fast, reliable circuit protection for power conversion, drives, and electronics. Designed for sensitive semiconductor devices like IGBTs, SCRs, and diodes, this fuse provides exceptional current limiting, quick response times, and certifications meeting international standards. Its ceramic body and flush mount design ensure easy installation and maintenance in industrial environments. Protect your equipment with trusted, certified fuse technology—shop now and enhance your system safety and performance with ease.
Buy Littelfuse PSR250 fuse now and ensure fast, reliable protection for your power semiconductor devices in critical industrial systems.
Frequently Asked Questions
Where can I buy Littelfuse PSR030FS0250Z?
You can click on the BUY or RFQ button to purchase PSR030FS0250Z from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part PSR030FS0250Z?
You can download the PSR030FS0250Z datasheet or visit the Littelfuse website for support.
Who is the manufacturer of PSR030FS0250Z?
Littelfuse
