Littelfuse RUEF250 PolySwitch Circuit Protector
The RUEF250 is a radial leaded PolySwitch resettable circuit protection device suitable for safety, industrial, and portable electronics. It features high voltage ratings, fast trip times, low resistance, and a hold current of 2.5A at room temperature. With a maximum voltage of 30V and current capacity of 100A, it is UL, CSA, TUV, and CQC approved. The device operates across a temperature range of -40°C to 85°C, with UL94 V-0 flame-retardant epoxy insulation. Designed for high-volume electronics, it offers excellent design flexibility and reliability.
Littelfuse RUEF250 PolySwitch Circuit Protector Specifications:
- Hold Current: 2.5A at 20°C
- Maximum Voltage: 30V
- Maximum Current: 100A
- Resistance: 0.07 ohms at 20°C one hour post-trip
- Operation Temperature: -40°C to 85°C
- Flame-retardant Epoxy Polymer: UL94 V-0
- Lead Material: Tin-plated Copper (24AWG)
- Solderability: Meets ANSI/J-STD-002 Category 3
- Solder Heat Tolerance: 10s at 260°C +5°C for larger sizes
- RoHS & ELV Compliant
- Agency Recognition: UL, CSA, TUV, CQC
Buy the PolySwitch 250 U 250 – Reliable Circuit Protection Device for Industrial Applications
Purchase the Littelfuse RUEF250 online today—designed for safety, reliability, and quick response in high-voltage electronic circuits. This radial leaded resettable device offers a maximum voltage of 30V, a hold current of 2.5A, and is approved by UL, CSA, TUV, and CQC. Its flame-retardant epoxy insulation ensures durability, while its low resistance of 0.07 ohms provides efficient protection for safety-critical applications. Ideal for industrial controls, portable electronics, and high-volume manufacturing, it guarantees excellent performance and long-term reliability.
Get Littelfuse RUEF250 today—built for high voltage and fast trip times in electronic safety and industrial protection.
Frequently Asked Questions
Where can I buy Littelfuse RUEF250?
You can click on the BUY or RFQ button to purchase RUEF250 from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part RUEF250?
You can download the RUEF250 datasheet or visit the Littelfuse website for support.
Who is the manufacturer of RUEF250?
Littelfuse
