Littelfuse V12MLA0805LNH Multilayer Varistor
The V12MLA0805LNH is a surface-mount multilayer varistor designed for transient voltage surge suppression. Manufactured with multilayer ceramic technology, it provides fast response times under 1ns, making it ideal for ESD, EFT, and surge protection in electronic circuits. Suitable for various applications on power supply, control, and signal lines, it features a compact 0805 package, supporting operation over -55°C to +125°C. Its high energy handling capacity ensures reliable performance with excellent current distribution and thermal stress reduction, enhancing overall device durability.
Littelfuse V12MLA0805LNH Multilayer Varistor Specifications:
- Package Size: 0805 (2.0 mm x 1.25 mm)
- Maximum DC Working Voltage: 12V
- Maximum AC Voltage: 9.0V
- Non-Repetitive Surge Current: 150A at 8/20μs waveform
- Energy Dissipation: 0.4J
- Operating Temperature Range: -55°C to +125°C
- Leakage Current at 25°C: Typically 5μA, Maximum 20μA
- Clamping Voltage at 10A: 26V
- Response Time: Less than 1 nanosecond
- Lead Material: Tin-plated, nickel barrier termination
- Certificate Compliance: RoHS
Buy the Buy Littelfuse V12MLA0805LNH Part Number V12MLA0805LNH Online
Purchase Littelfuse V12MLA0805LNH online for superior transient voltage surge suppression. Designed for rapid response and high energy absorption, this compact surface-mount device ensures circuit protection against surges, ESD, and EFT events. Its low leakage current and excellent thermal management make it ideal for power lines, control systems, and signal protection. Order now to benefit from fast shipping and ensure your electronics operate safely and reliably with this durable, RoHS-compliant multilayer ceramic varistor designed for modern electronic applications.
Get Littelfuse V12MLA0805LNH today—built for fast transient protection and reliable circuit safeguarding.
Frequently Asked Questions
Where can I buy Littelfuse V12MLA0805LNH?
You can click on the BUY or RFQ button to purchase V12MLA0805LNH from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part V12MLA0805LNH?
You can download the V12MLA0805LNH datasheet or visit the Littelfuse website for support.
Who is the manufacturer of V12MLA0805LNH?
Littelfuse
