Littelfuse V511BA60 Industrial Metal-Oxide Varistor
The V511BA60 is a heavy-duty industrial metal-oxide varistor (MOV) designed to provide surge protection for motor controls and power supplies in applications such as oil drilling, mining, transportation, and other heavy industrial AC line systems. This BA series transient surge suppressor features improved creep and strike capabilities to minimize breakdown risks, along with rigid terminals for secure wiring. Its case design ensures complete electrical isolation of the disc subassembly, and it can operate without derating up to an ambient temperature of 85°C. Suitable for industrial and power management applications.
Littelfuse V511BA60 Industrial Metal-Oxide Varistor Specifications:
- Size: 60mm diameter disc
- Voltage Range: 130V to 880V (BA Series), 1100V to 2800V (BB Series)
- Peak Pulse Current: 50,000 to 70,000 A
- Single Pulse Energy: 450 to 10,000 J
- Operating Temperature Range: -55°C to +85°C
- Storage Temperature Range: -55°C to +125°C
- Insulation Material: Cured, flame retardant epoxy polymer (UL94V-0)
- Lead Material: Copper with Tin Plating
- Maximum Clamping Voltage: Up to 880V (BA Series), 2800V (BB Series)
- Power Dissipation: Transients with a maximum average power dissipation of 2.5W
- Humidity Resistance: Meets MIL-STD-202, Method 215
- Resistance Change: Typical resistance change within +/-5% after 1000 hours at +85°C
- Isolation Voltage Capability: 5000V DC withstand
Buy the Buy Littelfuse Varistor Part Number V511BA60 Online
Enhance your system's surge protection with the V511BA60, a rugged industrial MOV designed for high-energy transient suppression. Ideal for motor controls, power supplies, and heavy industrial applications, this durable component operates efficiently at temperatures up to 85°C without derating. Easy to install with rigid terminals and complete electrical isolation, it features advanced creep and strike capability to minimize breakdown risk. Perfect for demanding environments like oil drilling, mining, and transportation, order online today for fast delivery and superior surge protection.
Buy Littelfuse V511BA60 compact surge protector now and ensure reliable motor control and power supply protection in heavy industrial environments.
Frequently Asked Questions
Where can I buy Littelfuse V511BA60?
You can click on the BUY or RFQ button to purchase V511BA60 from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part V511BA60?
You can download the V511BA60 datasheet or visit the Littelfuse website for support.
Who is the manufacturer of V511BA60?
Littelfuse
