LOCTITE 49945 General Purpose Adhesive
LOCTITE 499 is a versatile ethyl cyanoacrylate adhesive designed for a wide range of bonding applications. Its formulation provides excellent resistance to thermal cycling and humidity, making it ideal for environments with fluctuating temperatures and moisture exposure. It bonds effectively to rubbers, plastics, and metals, offering a strong and durable connection. The adhesive cures rapidly in the presence of moisture, developing full functional strength within a short time, although full chemical and solvent resistance takes approximately 24 hours. It is not recommended for use in pure oxygen or with strong oxidizing materials.
LOCTITE 49945 General Purpose Adhesive Specifications:
- Technology: Cyanoacrylate
- Chemical Type: Ethyl cyanoacrylate
- Appearance: Translucent colorless gel
- Components: One part
- Viscosity: High
- Cure: Humidity
- Application: Bonding
- Key Substrates: Rubbers, Plastics and Metals
- Specific Gravity @ 25 °C: 1.1
- Casson Viscosity, 25 °C, mPa·s (cP): 100 to 450
- Viscosity, Brookfield - RVT, 25 °C, mPa·s (cP): 18,000 to 40,000
- Vapour Pressure, hPa: ≤1
- Coefficient of Thermal Expansion: 100×10 [-6]
- Coefficient of Thermal Conductivity: 0.1 W/(m·K)
- Softening Point: 165 °C
- Dielectric Constant / Dissipation Factor, 0.1-kHz: 2 to 3.3 / <0.02
- Dielectric Constant / Dissipation Factor, 1-kHz: 2 to 3.5 / <0.02
- Dielectric Constant / Dissipation Factor, 10-kHz: 2 to 3.5 / <0.02
- Volume Resistivity: 2×1015 to 10×1015 Ω·cm
- Surface Resistivity: 10×1015 to 80×1015 Ω
- Dielectric Breakdown Strength: 25 kV/mm
- Lap Shear Strength (Steel, grit blasted): 18 to 26 N/mm² (2,610 to 3,770 psi)
- Lap Shear Strength (Aluminum): 11 to 19 N/mm² (1,595 to 2,755 psi)
- Lap Shear Strength (Zinc dichromate): 8 to 15 N/mm² (1,160 to 2,175 psi)
- Lap Shear Strength (ABS): 6 to 20 N/mm² (870 to 2,900 psi)
- Lap Shear Strength (PVC): 6 to 20 N/mm² (870 to 2,900 psi)
- Lap Shear Strength (Polycarbonate): 5 to 20 N/mm² (725 to 2,900 psi)
- Lap Shear Strength (Phenolic): 5 to 15 N/mm² (725 to 2,175 psi)
- Lap Shear Strength (Neoprene): 5 to 15 N/mm² (725 to 2,175 psi)
- Tensile Strength (Steel, grit blasted): ≥9.0 N/mm² (≥1,305 psi)
- Tensile Strength (Buna-N): ≥3.0 N/mm² (≥435 psi)
- T Peel Strength (Steel): 12 to 25 N/mm (1,740 to 3,625 psi)
