MAXIM INTEGRATED / ANALOG DEVICES MAX882CSAT Low-Noise Voltage Regulator
The MAX882CSA+T from Maxim Integrated Products is a low IQ, low dropout linear voltage regulator offered in an 8-pin NSOIC package. It provides high efficiency for battery-powered devices by combining ultra-low supply currents—drawing only 11µA from no load up to full load—and low dropout voltage of approximately 320mV at 200mA output current. The regulator features dual mode operation with fixed 3.3V or adjustable output voltage settings ranging from 1.25V to 11V, eliminating PNP transistor base current losses typical of traditional bipolar regulators. It supports a wide input voltage range from 2.7V to 11.5V and operates within a temperature range of 0°C to +70°C. Additional features include internal P-channel pass transistor with no base current draw, low output noise (250µVRMS from 10Hz to 10kHz), load regulation of 30mV, line regulation of 10mV, and foldback current limiting at 170mA. It also incorporates low battery detection, reverse current protection, and thermal overload protection. Applications include portable electronics such as pagers, cellular phones, high-efficiency linear regulators, solar-powered instruments, and automotive electronics.
MAXIM INTEGRATED / ANALOG DEVICES MAX882CSAT Low-Noise Voltage Regulator Specifications:
- Package: 8-pin NSOIC
- Output voltage: 1.25V to 11V (adjustable), fixed at 3.3V in preset mode
- Input voltage range: 2.7V to 11.5V
- Output current: up to 200mA
- Dropout voltage: approximately 320mV at 200mA
- Quiescent current: typically 11µA with no load to full load
- Output noise: 250µVRMS (10Hz to 10kHz)
- Line regulation: 10mV
- Load regulation: 30mV
- Foldback current limit: 170mA
- Features: low-battery detection, reverse current protection, thermal overload protection
- Operating temperature: 0°C to +70°C
Buy the Maxim Series MAX882 Low-Noise Voltage Regulator: MAX882CSAT
Invest in the Maxim MAX882CSAT low-noise linear voltage regulator for your portable and battery-powered projects. With ultra-low quiescent current of just 11µA and a wide input voltage range from 2.7V to 11.5V, it offers exceptional efficiency and stability. The adjustable output from 1.25V to 11V allows versatile power management solutions. Additional features include foldback current limiting at 170mA, low output noise of 250µVRMS, reverse current protection, and thermal overload safeguards. Perfect for pagers, cellular phones, solar-powered instruments, and other portable applications demanding reliable, low power consumption regulation.
Buy Maxim MAX882CSAT now and experience unmatched efficiency and reliable power regulation for portable electronics and battery-powered devices.
