MEAN WELL DDR15G12 DIN Rail Power Converter
The DDR-15G12 series is a high-reliability 15W DIN rail power converter designed for industrial control, communication systems, and security applications. Featuring ultra-wide input voltage ranges of 9-36V or 18-75V, it offers efficient power conversion with low ripple and noise. The device operates from -40°C to +85°C, includes reinforced isolation of 4KVdc, and provides adjustable output voltage (+10%). Its compact width of only 17.5mm supports easy DIN rail installation. Protected against short circuit, overload, overvoltage, reverse polarity, and under voltage, it ensures system stability and safety.
MEAN WELL DDR15G12 DIN Rail Power Converter Specifications:
- Dimensions: 17.5*90*54.5mm (W*H*D)
- Input Voltage: 9-36V or 18-75V, wide input range with 4:1 ratio
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V with ±2% tolerance
- Rated Power: 15W for all models
- Ripple & Noise: Max. 75mVp-p for 3.3V, 50mVp-p for 5V, 60mVp-p for 12V, 75mVp-p for 15V, 100mVp-p for 24V
- Efficiency: Up to 86% at full load
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 4KVdc reinforced isolation
- Protection: Short circuit, overload (110-150%), overvoltage, reverse polarity, undervoltage lockout
- Vibration & Humidity: Compliant with IEC standards, 5-95% RH non-condensing
- MTBF: Over 907,000 hours per MIL-HDBK-217F
- Mounting: DIN rail TS-35/7.5 or TS-35/15
- Standards: IEC 62368-1, UL listed design references
Buy the Mean Well Series DDR15 15W Power Converter: DDR15G12
Enhance your industrial control setup with the reliable DDR15 series 15W DIN rail power converter. Featuring ultra-wide input voltage ranges, adjustable outputs, and high temperature capacity, it ensures stable power delivery across various applications. Easy DIN rail installation, reinforced isolation of 4KVdc, and full protective features including short circuit, overload, overvoltage, reverse polarity, and under voltage make it suitable for factory automation, telecom, and security systems. Purchase online today for seamless integration and dependable operation in demanding environments.
Buy Mean Well DDR15G12 15W DIN Rail Power Converter now and experience unmatched reliability and performance for industrial control and communication systems.
Frequently Asked Questions
Where can I buy MEAN WELL DDR15G12?
You can click on the BUY or RFQ button to purchase DDR15G12 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR15G12?
You can download the DDR15G12 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR15G12?
MEAN WELL
