MEAN WELL DDR15G5 DIN Rail DC-DC Converter
The DDR-15G-5 series is a 15W DIN Rail DC-DC converter designed for industrial control, automation, and communication systems. It features an ultra-slim width of just 17.5mm, a wide input voltage range of 9~36V, and an adjustable output voltage (+10%). Operating efficiently from -40°C to +85°C, it provides full protections including short circuit, overload, over voltage, input reverse polarity, and undervoltage lockout. Its reinforced 4KVdc I/O isolation, compact size, and DIN rail mounting make it ideal for industrial, telecom, and data communication applications.
MEAN WELL DDR15G5 DIN Rail DC-DC Converter Specifications:
- Power: 15W
- Input Voltage: 9~36V or 18~75V
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V
- Adjustable Output Range: 30-36V, 45-5V, 9-13.2V, 13.5-16.5V, 21.6-28V
- Ripple & Noise: 50mVp-p to 400mVp-p depending on model
- Voltage Tolerance: ±2.0%
- Line Regulation: ±0.5%
- Load Regulation: 1% to 0.5%
- Operating Temperature: -40°C to +85°C
- Isolation: 4KVdc (Rising isolation)
- Protections: Short circuit, Overload, Over voltage, Reverse Polarity, Under voltage lockout
- Dimensions: 17.5 x 90 x 54.5mm
- Mounting: DIN rail TS-35/7.5 or TS-35/15
- Efficiency: 84% to 86%
- Humidity: 5-95% RH non-condensing
- Standards: IEC 62368-1, UL508
Buy the Mean Well Series DDR-15 15W DIN Rail DC-DC Converter: DDR15G5
Shop the reliable and efficient DDR15G5 DIN rail DC-DC converter online today for your industrial automation and communication needs. This 15W power supply offers wide input voltage ranges, adjustable output, and full protection features including short circuit, overload, and over voltage protection. Its compact 17.5mm width is suitable for tight installation environments on DIN rails. Designed for continuous operation from -40°C to +85°C, it ensures stable power delivery for industrial control, telecom, and security systems. Purchase online now for quick delivery and dependable performance.
Get Mean Well DDR15G5 today—compact, reliable, and designed for industrial control and telecom systems with wide input voltage and full protections.
Frequently Asked Questions
Where can I buy MEAN WELL DDR15G5?
You can click on the BUY or RFQ button to purchase DDR15G5 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR15G5?
You can download the DDR15G5 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR15G5?
MEAN WELL
