MEAN WELL DDR15L15 industrial DIN Rail power supply
The DDR15L15 series is a compact and efficient 15W DIN Rail-mounted DC-DC converter, suitable for industrial automation, control systems, and communication networks. It features ultra-wide input voltage ranges of 9~36V or 18~75V, wide operating temperature from -40°C to +85°C, and reinforced isolation of 4KVdc. The design supports adjustable output voltage, full protection functions including short circuit, overload, overvoltage, reverse polarity, and undervoltage lockout. Easy installation on TS-35/7.5 or 15 DIN rails makes it ideal for space-sensitive industrial environments. High efficiency and robust performance ensure reliable operation in demanding settings.
MEAN WELL DDR15L15 industrial DIN Rail power supply Specifications:
- Input Voltage: 9~36V or 18~75V
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V
- Rated Power: 15W
- Dimensions: 17.5mm (W) x 90mm (H) x 54.5mm (D)
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 4KVdc (reinforced)
- Ripple & Noise: 50-100mVp-p depending on model
- Efficiency: 84-86%
- Protection: Short circuit, overload, overvoltage, reverse polarity, UV lockout
- Mounting: TS-35/7.5 or 15 DIN rail
- Vibration Resistance: IEC60068-2-6 compliant
- MTBF: 907,000 hours
Buy the Buy Meanwell DDR-15 Series 15W DIN Rail DC-DC Converter Part Number DDR15L15 Online
Purchase the Meanwell DDR-15L15 series 15W DIN Rail DC-DC converter online today to experience dependable, high-efficiency power for your industrial automation, communication systems, or control applications. Easy to install on TS-35/7.5 or 15 DIN rails, this converter features ultra-wide input voltage ranges up to 75V, wide temperature tolerance from -40°C to +85°C, and reinforced isolation of 4KVdc. Robust protections including short circuit, overload, and reverse polarity ensure reliable operation in demanding environments. Upgrade your system with this durable, compact, and dependable power solution today.
Order your Meanwell DDR-15L15 series compact 15W DIN Rail DC-DC converter today and enhance your industrial control system with reliable, space-saving power solutions.
Frequently Asked Questions
Where can I buy MEAN WELL DDR15L15?
You can click on the BUY or RFQ button to purchase DDR15L15 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR15L15?
You can download the DDR15L15 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR15L15?
MEAN WELL
