MEAN WELL DDR15L33 Industrial DIN Rail Power Converter
The DDR-15L33 series is a 15W DIN Rail DC-DC converter designed for industrial environments, with a compact width of just 17.5mm. It features ultra-wide input voltage ranges of 18~75V DC, wide operating temperatures from -40°C to +85°C, and reinforced 4KV DC I/O isolation. The converter offers adjustable output voltage (+10%), full protection, and can be installed easily on DIN rails TS-35/7.5 or 15. It is suitable for industrial control, communication, security systems, and automation applications, providing reliable power in harsh environments.
MEAN WELL DDR15L33 Industrial DIN Rail Power Converter Specifications:
- Power: 15W
- Input Voltage: 18~75V DC
- Output Voltages: 3.3V, 5V, 12V, 15V, 24V
- Output Current: 3.54A (3.3V), 3A (5V), 1.25A (12V), 1A (15V), 0.63A (24V)
- Ripple & Noise: Max 50-400mVp-p depending on model
- Voltage Adjustment Range: 30-36V (3.3V), 45-5.5V (5V), 9-13.2V (12V), 13.5-16.5V (15V), 21.6-28V (24V)
- Voltage Tolerance: ±2.0%
- Line Regulation: ±0.5%
- Load Regulation: ±0.5%
- Efficiency: Approximately 84-86%
- Output Voltage Tolerance: ±2.0%
- Protection: Short circuit, Overload, Over-voltage, Reverse polarity, Under voltage lockout
- Isolation Voltage: 4KV DC (reinforced isolation)
- Operating Temperature: -40°C to +85°C
- Dimensions: 17.5mm W x 90mm H x 54.5mm D
- Mounting: DIN Rail TS-35/7.5 or TS-35/15
- Compliance: IEC 62368-1, UL508, CE
Buy the Meanwell Series DDR-15 15W DIN Rail DC-DC Converter: DDR15L33
Purchase the DDR15L33 series DIN Rail power supply online and enjoy fast, secure delivery of a high-quality, compact 15W DC-DC converter. Perfect for industrial automation, communications, and control systems, it offers ultra-wide input voltage ranges, adjustable outputs, excellent thermal performance from -40°C to +85°C, and reinforced 4KV isolation. Its easy DIN rail installation and comprehensive protections ensure reliable operation in harsh environments. Ensure your systems run smoothly by buying this dependable power converter today with hassle-free online shopping.
Buy Meanwell DDR15L33 now and experience unmatched reliability and performance with versatile wide input and industrial-grade protection features.
Frequently Asked Questions
Where can I buy MEAN WELL DDR15L33?
You can click on the BUY or RFQ button to purchase DDR15L33 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR15L33?
You can download the DDR15L33 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR15L33?
MEAN WELL
