MEAN WELL DDR60L5 Industrial DIN Rail Power Supply
The DDR-60L-5 series is a compact 60W DIN Rail DC-DC converter designed for industrial automation, control systems, and communication equipment. It features an ultra-wide input range of 9-36V or 18-75V, with adjustable output voltage of 5V ±10%. This power supply offers high efficiency, reinforced isolation of 4KV DC, and protections including short circuit, overload, and over-voltage. Its slim profile of 52.5mm width makes it ideal for space-constrained industrial applications. Capable of operating in temperatures from -40°C to +85°C, it ensures reliable performance in harsh environments.
MEAN WELL DDR60L5 Industrial DIN Rail Power Supply Specifications:
- Power: 60W
- Input Voltage: 9-36V or 18-75V (depending on model)
- Output Voltage: 5V with ±10% adjustment
- Rated Current: 10.8A (at 5V output)
- Ripple & Noise: Max. 60mVp-p
- Efficiency: Up to 91%
- Isolation Voltage: 4KV DC (reinforced isolation)
- Operating Temperature: -40°C to +85°C
- Dimensions: Width 52.5mm, Depth 64.5mm, Height 90mm
- Protections: Short circuit, overload, over-voltage, reverse polarity, under voltage lockout
- Certification: IEC 62368-1 approved, UL508 design
- Mounting: DIN Rail TS-35/7.5 or TS-35/15
- Cooling: Free air convection
- MTBF: 611,000 hours (min.)
- Working Humidity: 5-95% RH non-condensing
- Vibration: IEC60068-2-6 compliant
- Altitude: Up to 2000 meters
Buy the Mean Well DDR-60L-5 – Reliable Power Supply for Industrial Applications
Purchase the DDR-60L-5 series DIN rail power supply online today for reliable, space-saving power conversion. With its wide input range of 9-36V or 18-75V, adjustable 5V output, and reinforced 4KV isolation, it offers excellent performance for industrial control, automation, and communication systems. Its high efficiency, compact design, and robust protections ensure uninterrupted operation even in challenging environments. Get yours now and enhance your system's power stability and safety with a trusted solution that is engineered for demanding industrial conditions.
Order your Mean Well DDR-60L-5 series power supply today and ensure stable, efficient power for your industrial automation or control system projects.
Frequently Asked Questions
Where can I buy MEAN WELL DDR60L5?
You can click on the BUY or RFQ button to purchase DDR60L5 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR60L5?
You can download the DDR60L5 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR60L5?
MEAN WELL
