MEAN WELL HDR15012 Power Supply
HDR-150 is an economical 150W ultra slim DIN rail power supply designed for versatile industrial, building automation, and household applications. It features a compact 105mm width, full-range AC input (85–264VAC, 277VAC operational), high efficiency up to 90.5%, and multiple protections including short circuit, overload, and overvoltage. Suitable for TS-35/7.5 or TS-35/15 DIN rails, it operates reliably between -30°C and 70°C with cooling via free air convection. Certifications like IEC62368-1 and UL61010 ensure safety and compliance for automation and control systems.
MEAN WELL HDR15012 Power Supply Specifications:
- Model: HDR-150-12, HDR-150-15, HDR-150-24, HDR-150-48
- Input Voltage: 85–264VAC, 277VAC operational, 47–63Hz
- Output Voltage: 12V, 15V, 24V, 48V adjustable within specified ranges
- Rated Power: 150W
- Efficiency: Up to 90.5%
- Ripple & Noise: Max 100mVp-p to 200mVp-p depending on model
- Output Voltage Tolerance: ±2.0% to ±10%
- Protection: Short circuit, overload, overvoltage, shut down with auto-recovery
- Operating Temp: -30°C to 70°C, derating above 45°C at 3.5°C/1000m altitude
- Dimensions: 105mm (W) x 54.5mm (H) x 58.4mm (D), full compliance with IEC standards
- Mounting: DIN rail TS-35/7.5 or TS-35/15
- Isolation Resistance: 100MΩ at 500VDC
- Certifications: IEC62368-1, UL62368-1, UL61010, EN61558-2-16
Buy the Meanwell Series HDR-150 150W Power Supply: HDR15012
Experience reliable power delivery with the Meanwell HDR15012 ultra slim 150W DIN rail power supply. Designed for industrial control, automation, and household use, it features a compact size, universal input voltage, and high efficiency up to 90.5%. This power supply offers multiple protections including short circuit, overload, and overvoltage protection. It mounts easily on TS-35/7.5 or TS-35/15 DIN rails, making installation straightforward and space-efficient. Perfect for factory automation, building automation, and electro-mechanical devices, ensuring consistent performance and safety standards.
Get Meanwell HDR15012 today—built for precision, high efficiency, and long-lasting durability in industrial automation
Frequently Asked Questions
Where can I buy MEAN WELL HDR15012?
You can click on the BUY or RFQ button to purchase HDR15012 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HDR15012?
You can download the HDR15012 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HDR15012?
MEAN WELL
