MEAN WELL HLG120H24A LED Driver
The HLG-120H series is a versatile 120W LED driver capable of operating in both constant voltage and constant current modes. Designed for indoor and outdoor use, it features high efficiency up to 93.5%, with a fanless cooling system adaptable to temperatures from -40°C to +80°C. The series has an IP67/IP65 rating, allowing installation in harsh environments such as street lighting, high-bay lights, and outdoor signage. Optional functions include adjustable output voltage, 3-in-1 dimming, timer dimming, and multiple safety and protection features. Its robust metal housing and broad voltage input range enhance durability and flexibility.
MEAN WELL HLG120H24A LED Driver Specifications:
- Rated Power: 120W
- Input Voltage: 90-305VAC, 47-63Hz
- Output Voltage Range: 12V to 54V (model dependent)
- Rated Current: 10A, 6A, 5A, 4A, etc. (model dependent)
- Ripple & Noise: Max. 200mVp-p
- Efficiency: Up to 93.5%
- Protection: Over current, short circuit, over voltage, over temperature, auto recovery
- Lifetime: >62,000 hours at Ta ≤ 75°C
- Operating Temperature: -40°C to +80°C
- Ingress Protection: IP67/IP65 (model dependent)
- Dimensions: 220mm (L) x 68mm (W) x 38.8mm (H)
- Vibration Resistance: 5G, 40-500Hz
- EMC & Safety Standards: EN55032 (Class B), UL, CSA, EN60950-1
- Power Factor: ≥0.98 at 115VAC, ≥0.95 at 230VAC
- Total Harmonic Distortion: <20% at full load
- Dimming Options: 3-in-1 (1-10V, PWM, resistance), Timer dimming (optional)
Buy the Mean Well Series LED Driver: HLG Series 120W: HLG120H24A
Upgrade your lighting system with the 120W LED driver from the trusted HLG series. Designed for indoor and outdoor applications, this driver offers high efficiency up to 93.5%, broad input voltage compatibility, and multiple dimming options. Its IP67/IP65 housing ensures durability in harsh environments, while over-current, over-voltage, and temperature protections safeguard your investments. Easy to install, energy-efficient, and long-lasting, the HLG-120H series provides excellent performance for street lighting, high-bay, and signage solutions. Order online today for reliable lighting performance.
Buy Mean Well HLG120H24A now and experience unmatched reliability and performance with versatile dimming and robust outdoor ratings.
Frequently Asked Questions
Where can I buy MEAN WELL HLG120H24A?
You can click on the BUY or RFQ button to purchase HLG120H24A from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HLG120H24A?
You can download the HLG120H24A datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HLG120H24A?
MEAN WELL
