MEAN WELL HLG120H48A LED Driver
The HLG-120H series is a 120W AC/DC LED driver designed for versatile indoor and outdoor lighting applications, including street, high-bay, parking, greenhouse, and fishing lamps. It features dual mode operation with constant voltage and current outputs, high efficiency up to 93.5%, and a fanless design for reliable continuous operation from -40°C to +80°C. With ingress protection levels IP67/IP65, it withstands harsh environments. Multiple dimming options, adjustable outputs, and a robust metal housing make it ideal for reliable, flexible, and long-lasting LED lighting installations, backed by a 7-year warranty.
MEAN WELL HLG120H48A LED Driver Specifications:
- Rated Power: 120W
- Input Voltage: 90 ~ 305VAC
- Output Voltage Range: 12V to 54V
- Rated Current: 10A (12V), 6A (15V), 5A (20V), 4A (24V), 3.44A (30V), 2.9A (36V), 2.5A (42V), 2.3A (48V), 2.3A (54V)
- Ripple & Noise: Max. 150-200mVp-p depending on model
- Efficiency: Up to 93.5%
- Operating Temperature: -40°C to +80°C
- Ingress Protection Level: IP67/IP65
- Dimming Options: 1~10VDC, PWM signal, resistance, timer (contact manufacturer for details)
- Dimensions: 220mm x 68mm x 38.8mm
- Certificates: UL, CSA, EN/AS/NZS 61347-1, 61347-2-13, CB, TUV, GB19510.1, BIS, EAC, KC
- Power Factor: 0.98/115VAC, 0.95/230VAC, 0.93/277VAC
- Total Harmonic Distortion: <20% at 50-75% load
- Lifetime: >62,000 hours at Tcase ≤75°C
- Protection Features: Over voltage, over temperature, short circuit, constant current limiting
- Physical: Metal housing, waterproof connectors, suitable for damp and outdoor environments
Buy the Mean Well Series HLG120H LED Driver: HLG-120H48A
Discover the high-performance Mean Well LED driver, designed for indoor and outdoor applications. With a power output of 120W, adjustable voltage and current, and multiple dimming methods, it offers exceptional flexibility for various LED lighting setups. Its IP67/IP65 ratings ensure durability in harsh environments while maintaining efficiency up to 93.5%. The durable metal housing combined with built-in protections provides reliable, long-lasting operation. Purchase online today for a versatile, dependable LED power solution with a 7-year warranty, perfect for commercial, industrial, and outdoor lighting installations.
Buy Mean Well HLG-120H48A now and experience unmatched reliability, high efficiency, and versatile dimming for professional LED lighting projects.
