MEAN WELL HLG240H12B LED Driver
The HLG-240H series is a high-efficiency, 240W AC/DC LED driver supporting dual constant voltage and constant current modes. Operable from 90 to 305VAC, it offers various rated voltages between 12V and 54V, with an efficiency up to 93.5%. Featuring a fanless design and robust metal housing with IP67/IP65 ratings, it is suitable for indoor and outdoor applications, including street lighting, high-bay lighting, and hazardous location setups. Multiple dimming options, adjustable output, and a lifespan exceeding 62,000 hours make this series versatile for diverse LED lighting systems.
MEAN WELL HLG240H12B LED Driver Specifications:
- Rated Power: 240W
- Input Voltage: 90~305VAC
- Output Voltage: 12V to 54V (model dependent)
- Rated Current: 16A @ 12V, 14.5A @ 15V, 12A @ 20V, 10A @ 24V, etc.
- Efficiency: Up to 93.5%
- Ripple & Noise: Max 150mVp-p to 350mVp-p (model dependent)
- IP67/IP65 ingress protection
- Operating Temperature: -40°C to +90°C
- Lifetime: >62,000 hours at Tcase ≤75°C
- Dimming options: 3-in-1 (1-10VDC, PWM, resistance)
- Protection: Overcurrent, overvoltage, short circuit, thermal shutdown
- Mechanical Dimensions: Approximately 244.2mm x 68mm x 38.8mm
- Certifications: UL, CSA, CE, EN EC, RoHS compliance
- Operating Humidity: 20~95% RH (non-condensing)
Buy the Mean Well Series HLG240H12B LED Driver: Reliable Power Solution with IP65/IP67 Rating
Discover the reliable 240W LED driver designed for demanding indoor and outdoor lighting applications. Featuring high efficiency, IP67/IP65 ratings, and multiple dimming options, this driver ensures optimal performance and longevity. Easy to install with adjustable output voltage and current, it’s perfect for street lighting, high-bay, and hazardous locations. The fanless design maintains quiet operation, while the lifespan exceeds 62,000 hours. Buy online today to enhance your LED lighting system with a durable, efficient, and versatile power solution.
Get Mean Well 240W today—built for precision, durability, and versatile LED lighting solutions in industrial environments.
Frequently Asked Questions
Where can I buy MEAN WELL HLG240H12B?
You can click on the BUY or RFQ button to purchase HLG240H12B from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HLG240H12B?
You can download the HLG240H12B datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HLG240H12B?
MEAN WELL
