MEAN WELL IDLV25A12 LED Driver
The IDLV-25 series is a 25W LED driver designed for constant voltage PWM output, operating from 90 to 295VAC. It offers models with rated voltages from 12V to 60V, featuring high efficiency up to 84%, fanless operation, and a wide temperature range of -20°C to +90°C. Equipped with various dimming options including 2-in-1 dimming (0-10VDC and PWM), and auxiliary DC output, it is suitable for indoor LED lighting, decorative lighting, and LED architecture applications. Its robust construction and advanced features ensure reliable performance in demanding environments. Warranty is 3 years.
MEAN WELL IDLV25A12 LED Driver Specifications:
- DC Voltage: 12V/24V/36V/48V/60V
- Rated Power: 21.6W to 25.2W depending on model
- Efficiency: up to 84%
- Dimming Range: 0-100%
- Input Voltage Range: 90-295VAC
- Frequency Range: 47-63Hz
- Working Temperature: -20°C to +90°C
- Dimensions: 110 x 75 x 22 mm
- Protection: Over current, short circuit, over temperature
- Leakage Current: <0.75mA at 277VAC
- No Load Power Consumption: <0.5W (Blank-type), <1.2W (A-type)
- Safety: Withstand Voltage I/P-O/P 3.75KVAC
- EMC Compliance: EN55015, EN61000-3-2, EN61000-3-3
- MTBF: 382.7K hours
- Vibration: 10-500Hz, 2G
Buy the Buy Mean Well LED Driver Part Number IDLV25A12 Online
Purchase the Mean Well LED Driver designed for indoor LED and decorative lighting applications. With PWM output, high efficiency up to 84%, and versatile dimming options, it ensures optimal performance for LED strip lighting and architecture displays. It operates from 90 to 295VAC with models available from 12V to 60V. Its robust construction and built-in protection make it ideal for demanding environments. Enjoy fast delivery and expert support when you buy online today for a reliable and efficient lighting solution.
Get Mean Well IDLV25A12 today—built for high efficiency, adjustable dimming, and reliable indoor LED lighting solutions.
Frequently Asked Questions
Where can I buy MEAN WELL IDLV25A12?
You can click on the BUY or RFQ button to purchase IDLV25A12 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part IDLV25A12?
You can download the IDLV25A12 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of IDLV25A12?
MEAN WELL
