MEAN WELL IRM0115S Miniature AC-DC Power Module
IRM-01 series is a compact 1W encapsulated AC-DC power supply module, measuring 33.7*22.2*15mm. It supports universal input voltage 85~305VAC, offering high efficiency up to 77%, low no-load consumption below 0.075W, and robust design with phenolic case and fully-potted silicone for heat dissipation, dust, and moisture resistance. Suitable for industrial, automation, and electronic equipment, it meets safety standards UL60950-1, TUV EN60950-1, and complies with EN55022 Class B EMI standards. Its high reliability and low cost make it ideal for various industrial applications.
MEAN WELL IRM0115S Miniature AC-DC Power Module Specifications:
- Power: 1W
- Input Voltage: 85~305VAC
- Output Voltage: 3.3V, 5V, 9V, 12V, 15V, 24V
- Output Current: 300mA, 200mA, 111mA, 83mA, 67mA, 42mA respectively
- Ripple & Noise: Max. 150mVp-p for most models, 200mVp-p for others
- Voltage Tolerance: ±2.5%
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- Efficiency: Up to 77%
- Operating Temp.: -30°C to +85°C
- Storage Temp.: -40°C to +100°C
- Humidity: 20% to 90% RH non-condensing
- Protection: Overload, Overvoltage, Short Circuit
- Isolation Voltage: U/P-0: 3KV AC
- Safety Standards: UL60950-1, TUV EN60950-1, optional IEC60601-1
- EMC: EN55022 Class B, EN61000-3-2/-3, EN61000-4-2/3/4/5/6/8/11
- Dimensions: 33.7*22.2*15mm
Buy the Mean Well IRM-01 – Reliable 1W Power Supply for Industrial Applications
Buy your IRM-01 series miniature AC-DC power supply online today and enjoy a reliable, efficient power source perfect for industrial automation and electronic equipment. With universal input voltage, high efficiency up to 77%, and low no-load consumption under 0.075W, it complies with safety and EMI standards. Its compact design and robust construction ensure durability, dust, and moisture resistance, making it ideal for various industrial environments. Secure your supply today and optimize your electronic devices' performance with our trusted power modules.
Order your Mean Well IRM-01 power supply today and ensure your industrial projects benefit from dependable, efficient power solutions.
Frequently Asked Questions
Where can I buy MEAN WELL IRM0115S?
You can click on the BUY or RFQ button to purchase IRM0115S from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part IRM0115S?
You can download the IRM0115S datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of IRM0115S?
MEAN WELL
