MEAN WELL DETN02M05 2W DC-DC Unregulated Converter
The MEAN WELL DETN02 series is a 2W isolated and unregulated DC-DC converter module with an SMD package. It features an international standard pinout, high efficiency up to 83%, a wide working temperature range of -40°C to +100°C, 3KVDC isolation voltage, compliance with BS EN/EN55032 radiated Class A, short circuit protection, and more. Models accommodate different input voltages (5V/12V/24V ±10%) and various output voltages (±5V/±12V/±15V) for dual output, suitable for industrial control, telecommunication, and distributed power architectures.
MEAN WELL DETN02M05 2W DC-DC Unregulated Converter Specifications:
- Operating Temperature Range: -40 ~ +100℃
- Input Voltage: 5V/12V/24V
- Output Voltage: +/-5V, +/-12V, +/-15V
- Efficiency: Up to 83%
- Isolation Voltage: 3KVDC
- Protection: Short Circuit
- Switching Frequency: 100KHz
- Case Temperature: +105℃ max.
- Warranty: 3 years
Buy the DETN02M-05 MEAN WELL 2W DC-DC Unregulated Converter | myMectronic
Purchase the MEAN WELL DETN02M-05 2W DC-DC Unregulated Converter securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy MEAN WELL DETN02M05?
You can click on the BUY or RFQ button to purchase DETN02M05 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DETN02M05?
You can download the DETN02M05 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DETN02M05?
MEAN WELL
