MEAN WELL IRM019S Miniature Power Module
IRM-01 is a compact 1W AC-DC power supply module designed for electronic and industrial automation applications. It features a universal input voltage range of 85~305VAC, high efficiency up to 77%, and low no-load power consumption below 0.075W. Encased in a phenolic case with silicone potting, it offers excellent heat dissipation, dust, and moisture resistance, and anti-vibration up to 5G. Compliant with EN55022 Class B EMC standards, it integrates EMI filtering, ensuring electromagnetic interference immunity. Suitable for PCB mounting or SMD styles, it guarantees reliable operation in harsh environments, with protections for overload and overvoltage, and a 3-year warranty.
MEAN WELL IRM019S Miniature Power Module Specifications:
- Input Voltage Range: 85~305VAC
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V
- Rated Power: 1W
- Ripple & Noise: 150mVp-p (3.3V, 5V, 9V, 12V), 200mVp-p (15V, 24V)
- Voltage Tolerance: ±2.5%
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- Efficiency: Up to 77%
- No-load Power Consumption: <0.075W
- Operating Temperature: -30°C to +85°C
- Vibration Resistance: 5G
- Protection: Short Circuit, Overload, Overvoltage
- Isolation Resistance: 100MΩ at 500VDC
- Safety Standards: UL60950-1, TUV EN60950-1, optional IEC60601-1
- EMC Compliance: EN55022 Class B, EN61000-3-2, -3
- MTBF: 1960 hours at 25°C
Buy the Buy MEAN WELL 1W Power Supply Part Number IRM-01-5 Online
Purchase the MEAN WELL IRM-01 miniature power supply online today. Designed for industrial and electronic equipment, it features a universal voltage input, high efficiency up to 77%, and low power consumption under no load. Its rugged casing provides excellent heat dissipation and vibration resistance up to 5G, ensuring reliable operation in harsh environments. Compliant with global EMC standards, it includes protections for overload and overvoltage, making it ideal for PCB or SMD mounting in automation and instrumentation devices. Get yours now for quality and durability.
Get MEAN WELL IRM-01-5 today—compact, high efficiency, and built for reliable industrial and electronic applications.
Frequently Asked Questions
Where can I buy MEAN WELL IRM019S?
You can click on the BUY or RFQ button to purchase IRM019S from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part IRM019S?
You can download the IRM019S datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of IRM019S?
MEAN WELL
