MEAN WELL LPHC18350 Outdoor LED Power Supply
The LPHC-18-350 is a 48V, 16.8W, single-output switching power supply that is fully encapsulated with an IP67 protection rating, suitable for outdoor applications. It features cooling by free air convection and operates in constant current mode. The power supply is a Class II power unit, passes limited power source standards, and has undergone 100% full load burn testing. It offers 3% load regulation, 1% line regulation, and includes protections against short circuits, overvoltage, and overheating. Ideal for LED lighting and power management applications, this reliable power supply is suitable for outdoor signage and lighting projects.
MEAN WELL LPHC18350 Outdoor LED Power Supply Specifications:
- Input Voltage Range: 180~264VAC, 254~370VDC
- Rated Power: 16.8W
- Output Voltage Range: 6~48V
- Rated Current: 350mA
- Ripple & Noise (max.): 300mVp-p
- Line Regulation: 1%
- Load Regulation: 3%
- Efficiency (Typ.): 80%
- Protection: Short circuit, Over voltage, Over temperature
- Protection Type: Hiccup mode, recovers automatically
- Operating Temperature: -30°C to +70°C
- Humidity: 20% to 90%, non-condensing
- IP67 fully encapsulated, outdoor use capable
- Dimensions: Approximately 140×30×22 mm
- Vibration: 40~500Hz, 2G, 10 min. per axis
- Safety Standards: UL1310, TUV EN60950-1, CSA
- Isolation Resistance: >100M Ohms / 500VDC
- MTBF: 1200.6K hours
Buy the ANA Series LED Power Supply: LPHC18350
Order the ANA Series outdoor LED power supply LPHC18350 online today for reliable performance and weatherproof IP67 protection. Designed for LED lighting, signage, and other outdoor applications, this 18W power supply features constant current regulation, high efficiency, and comprehensive protections including short circuit, overvoltage, and over temperature. Its fully encapsulated design ensures durability in harsh environments, while the solution's compact size makes installation straightforward. Trust ANA's quality for long-lasting, secure power delivery to your outdoor LED projects—order now for fast, convenient online purchase.
Get ANA Series LPHC18350 today—built for LED lighting efficiency and outdoor durability.
Frequently Asked Questions
Where can I buy MEAN WELL LPHC18350?
You can click on the BUY or RFQ button to purchase LPHC18350 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part LPHC18350?
You can download the LPHC18350 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of LPHC18350?
MEAN WELL
