MEAN WELL MDR1012 Industrial Power Supply
This 10W single output industrial DIN rail power supply from the MDR-10 series provides reliable, efficient power with features like universal AC input, protections against short circuits, overloads, and overvoltage, and is designed for easy DIN rail mounting. It includes built-in DC OK active signal, LED indicator for power status, and supports a wide voltage range from 85V to 264VAC or 120V to 370VDC. Suitable for industrial automation, control systems, and manufacturing environments, it delivers stable output with excellent regulation, low ripple noise, and high efficiency, backed by a 3-year warranty.
MEAN WELL MDR1012 Industrial Power Supply Specifications:
- Power Output: 10W
- Input Voltage Range: 85-264VAC / 120-370VDC
- Output Voltage Options: 12V, 18V, 24V
- Rated Current: 2A at 12V, 0.84A at 18V, 0.42A at 24V
- Efficiency: Approx. 81%
- Protections: Short circuit, overload, overvoltage
- Cooling Method: Free air convection
- Dimensions: 22.5mm (W) x 90mm (H) x 100mm (D)
- Operating Temperature: -20°C to +70°C
- Storage Temperature: -40°C to +85°C
- Vibration Resistance: 10-500Hz, 2G
- Standards Compliance: UL508, TUV EN60950-1, EAC TP TC 004
- MTBF: 584,000 hours (MIL-HDBK-217F)
- No Load Power Consumption: <0.75W
- Reinforced safety and EMC standards including EN55011, EN61000-4 series
Buy the Meanwell MDR-10-12 Reliable Power Supply for Industrial Applications
Order the reliable industrial power supply online today to ensure your automation and control systems operate smoothly. Designed for durability, it offers universal input voltage, multiple protections, low noise, high efficiency, and easy DIN rail mount. Perfect for industrial automation, manufacturing, and control applications, this power supply provides stable, consistent power with a built-in DC OK signal, LED indicators, and a robust construction tested to meet international safety standards. Secure your equipment’s power needs with convenience and confidence today.
Get Meanwell MDR-10-12 today—built for precision, efficiency, and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy MEAN WELL MDR1012?
You can click on the BUY or RFQ button to purchase MDR1012 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part MDR1012?
You can download the MDR1012 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of MDR1012?
MEAN WELL
