MEAN WELL OWA60E36 Moistureproof Power Supply
The moistureproof power supply series delivers 60W with IP67 waterproof level, fully encapsulated in silicone for excellent heat dissipation and dust resistance. It supports universal input from 90VAC to 264VAC, achieving up to 91% efficiency and meeting strict energy standards including EU ErP and CoC V5. Designed for outdoor and damp environments, it features protections against short circuit, overload, overvoltage, and temperature. With a compact plastic case and fanless convection cooling, it ensures reliable operation in harsh conditions, making it ideal for household appliances, battery charging, and electronic equipment in humid or dusty environments.
MEAN WELL OWA60E36 Moistureproof Power Supply Specifications:
- Output Power: 60W
- Output Voltage: 12V, 15V, 20V, 24V, 30V, 36V, 42V, 48V, 54V
- Rated Current: 5A, 4A, 3.25A, 2A, 1.674A, 1.5A, 1.254A, 4.124A
- Ripple & Noise: 150–350mVp-p depending on model
- Input Voltage Range: 90–264VAC
- Efficiency: up to 91%
- Operating Temperature: -35°C to +70°C
- Protection: Short circuit, Overload, Over voltage, Over temperature
- Isolation Voltage: 3.75kVAC
- Enclosure: Fully plastic, IP67 rated silicone potting
- Standards: EN61558-2-16, EN60335-1 (select models), EAC
- Dimensions: 130mm x 53mm x 35mm
- Humidity: 20–95% RH non-condensing
- Vibration: 10–500Hz, 5G
- Cooling: Fanless, convection
- Warranty: 5 years
Buy the Mean Well 60W Series – Reliable Moistureproof Power Supply for Industrial Applications
Discover the robust and highly efficient moistureproof power supply designed for outdoor and damp conditions. With IP67 waterproofing, universal input, and protections against faults, this 60W series ensures reliable operation in dusty, humid environments. Its fanless convection cooling and compact design make it ideal for household appliances, battery charging, and electronic devices requiring dust, humidity, and moisture resistance. Trust the quality of this energy-efficient, safety-compliant power unit for your toughest outdoor applications and enjoy peace of mind with a 5-year warranty.
Order your Mean Well Series OWA-60E36 60W moistureproof power supply today and ensure dependable performance in humid and dusty environments.
Frequently Asked Questions
Where can I buy MEAN WELL OWA60E36?
You can click on the BUY or RFQ button to purchase OWA60E36 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part OWA60E36?
You can download the OWA60E36 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of OWA60E36?
MEAN WELL
