MEAN WELL PWM20048 200W Constant Voltage PWM Output
The MEAN WELL PWM-200-48 series is a 200W AC/DC LED driver designed for constant voltage applications. It utilizes PWM output to maintain consistent color temperature and brightness across LED strips and bulbs. The built-in KNX interface simplifies integration and offers protection against data manipulation. This driver is suitable for indoor LED lighting, decorative lighting, and architectural lighting projects, offering a reliable and efficient solution for various lighting needs.
MEAN WELL PWM20048 200W Constant Voltage PWM Output Specifications:
- Model: PWM-200-48
- DC Voltage: 48V
- Rated Current: 4.17A
- Rated Power: 200.1W
- Output: Constant Voltage PWM
- Setup Rise Time: 500ms, 80ms/230VAC, 1200ms, 80ms/115VAC
- Hold Up Time: 10ms/230VAC or 115VAC
- Voltage Range: 100 ~ 305VAC, 142 ~ 431VDC
- Frequency Range: 47 ~ 63Hz
- Power Factor: >0.94 @ 277VAC
- Efficiency: 92%
- AC Current: 0.75mA / 277VAC
- Input: 100 ~ 305VAC
- Inrush Current: COLD START 65A
- Leakage Current: <0.75mA / 277VAC
- Safety Standards: UL8750, CSA C22.2 No. 250.13-12, ENEC BS EN/EN61347-1
- Working Temp: -40 ~ +85℃
- Working Humidity: 20 ~ 95% RH non-condensing
- Storage Temp, Humidity: -40 ~ +85℃, 10 ~ 95% RH
- Temp Coefficient: ±0.03%/℃(0 ~ 50℃)
- Vibration: 10 ~ 500Hz, 5G
- MTBF: 1658.9 K hrs
- Dimension: 195*68*39.5mm
- PWM Frequency: 200~4000Hz user changable via ETS
- Dimming Range: 13 ~ 18V
- Overload: 108 ~ 135% rated output power
- Over Voltage: Shut down o/p voltage, re-power on to recover
- Over Temperature: Shut down o/p voltage, re-power on to recover
Buy the PWM-200-48 MEAN WELL 200W Constant Voltage PWM Output | myMectronic
Purchase the MEAN WELL PWM-200-48 securely and efficiently for your LED lighting projects.
Buy Now
Frequently Asked Questions
Where can I buy MEAN WELL PWM20048?
You can click on the BUY or RFQ button to purchase PWM20048 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part PWM20048?
You can download the PWM20048 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of PWM20048?
MEAN WELL
