MEAN WELL RSP15033 Industrial Power Supply
The RSP-150 series offers 150W single output power supplies with active PFC, universal AC input, and protections against short circuit, overload, overvoltage, and temperature. These compact, low-profile units feature remote ON-OFF control, LED power indicators, and operate efficiently within a temperature range of -30°C to +70°C. Suitable for industrial applications, their robust design includes built-in current limiting, high efficiency, and compliance with safety and EMC standards, ensuring reliable performance in demanding environments.
MEAN WELL RSP15033 Industrial Power Supply Specifications:
- Input Voltage: 85-264VAC, 120-370VDC
- Output Power: 150W
- Output Voltage Range: 3.14–3.63V (3.3V), 4.75–5.5V (5V), 7.13–8.25V (7.5V), 11.4–13.2V (12V), 12.8–14.9V (13.5V), 14.3–16.5V (15V), 22.8–26.4V (24V), 25.7–29.7V (27V), 45.6–52.8V (48V)
- Rated Current: 30A (3.3V), 30A (5V), 20A (7.5V), 125A (12V), 11.28A (13.5V), 10A (15V), 6.3A (24V), 56A (27V), 3.24A (48V)
- Ripple & Noise: Max 150mVp-p (some models 250mVp-p)
- Efficiency: Up to 90%
- Protections: Short circuit, overload, overvoltage, over temperature
- Operating Temperature: -30°C to +70°C
- Dimension: 199 x 99 x 30mm
- Certifications: UL, TUV, EN, CCC, GB standards
- Remote ON-OFF control: 0-0.8VDC ON, 4-10VDC OFF
- Hold-up Time: 46ms at full load
- Input Frequency Range: 47–63Hz
- MTBF: 290,700 hours
- Safety & EMC Compliance: EN55022 Class B, EN61000-4-2/3/4/5/6/8/11
Buy the MW RSP-150 Series – Reliable Power Supply for Industrial Applications
Purchase the MW RSP-150 series online today to ensure your industrial systems operate reliably. These 150W power supplies feature active PFC, universal input, and high efficiency. Designed for demanding environments, they include protections against short circuits, overloads, overvoltage, and temperature extremes. Compact and low-profile at 30mm, they provide remote ON-OFF control and operate over a broad temperature range. Backed by certification standards and a 3-year warranty, these power supplies are ideal for automation, control panels, and industrial equipment.
Get MW RSP-150 series today—built for precision, durability, and extensive protections in industrial environments.
Frequently Asked Questions
Where can I buy MEAN WELL RSP15033?
You can click on the BUY or RFQ button to purchase RSP15033 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part RSP15033?
You can download the RSP15033 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of RSP15033?
MEAN WELL
