MEAN WELL RSP32048 industrial power supply
The RSP-320-48 is a high-efficiency, 320W power supply featuring active PFC, universal AC input, and a built-in DC fan for forced air cooling. Its compact 1U 30mm low-profile design includes protections such as overvoltage, overload, short circuit, and over temperature, ensuring reliable operation in industrial applications. The unit supports a wide input voltage range, high power factor, and conformal coating option for harsh environments. It is certified to safety and EMC standards, with a typical efficiency of up to 90%. Suitable for industrial automation, control systems, and manufacturing equipment.
MEAN WELL RSP32048 industrial power supply Specifications:
- Input Voltage Range: 88~264VAC, 124~370VDC
- Rated Power: 320W
- Output Voltage: 48V
- Rated Current: 6.7A
- Ripple & Noise: 150mVp-p
- Efficiency: 87%
- Protection: Over voltage, over current, short circuit, over temperature
- Dimensions: 215*115*30mm (L*W*H)
- Vibration Resistance: 10~500Hz, 2G, 60min along X, Y, Z axes
- Operating Temperature: -30°C to +70°C (derating applicable)
- Certifications: UL60950-1, TUV EN60950-1, CCC GB4943
- EMC: EN55022 Class B, EN61000-4 immunity standards
- Built-in Fan for active cooling
- Conformal coating option for harsh environments
- 3-year warranty
Buy the Buy MEAN WELL Power Supply Part Number RSP32048 Online
Enhance your industrial automation projects with the MEAN WELL RSP-320-48 power supply. This 320W unit offers high efficiency, active PFC, and broad input voltage range for versatility. Built-in fan ensures optimal cooling, while multiple protections safeguard your equipment. The conformal coating option enables operation in harsh environments. Certified to safety and EMC standards, it features a compact 1U low-profile design suitable for space-constrained setups. Invest in quality with the 3-year warranty and quick online purchase for your manufacturing, control, and automation needs.
Order your MEAN WELL SeriesRSP32048 48V 6.7A power supply today and secure reliable, efficient power for your industrial control projects.
Frequently Asked Questions
Where can I buy MEAN WELL RSP32048?
You can click on the BUY or RFQ button to purchase RSP32048 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part RSP32048?
You can download the RSP32048 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of RSP32048?
MEAN WELL
