MEAN WELL SD200D12 Industrial Power Converter
The SD200D12 is a 200W single output DC-DC converter designed for industrial applications. It features a wide input range of 19–36V DC, high efficiency of 82%, and robust protections including short circuit, overload, over voltage, and over temperature. This converter offers 1500VAC isolation, cooling by free air convection, and passes a 100% burn-in test. Suitable for various automation and control systems, it ensures reliable power delivery in demanding environments with an operating temperature of -20°C to +60°C and compliance with safety standards IEC60950-1 and UL60950-1.
MEAN WELL SD200D12 Industrial Power Converter Specifications:
- Input Voltage Range: 19–36VDC
- Output Voltage: 12V
- Rated Power: 200W
- Rated Current: 16.7A
- Efficiency: 82%
- Ripple & Noise: 420mVp-p
- Isolation Voltage: 1500VAC
- Protection: Short circuit, Overload, Over voltage, Over temperature
- Dimensions: 215mm x 415mm x 50mm
- Working Temperature: -20°C to +60°C (derating from 50°C)
- Humidity Range: 20-90% RH non-condensing
- Vibration Resistance: 10-500Hz, 2G
- Standards: IEC60950-1, UL60950-1, CB
- MTBF: 218.2K hours minimum
Buy the Buy Mean Well SD200D12 Part Number SD200D12 Online
Purchase the Mean Well SD200D12 industrial power converter online today and enjoy reliable, high-efficiency power supply for automation systems. It provides a stable 12V output with 200W capacity, wide input voltage, comprehensive protections, and ISO 1500VAC. Perfect for demanding environments requiring stability, safety, and durability. With a compact design measuring 215mm x 415mm x 50mm and compliance with safety standards, it ensures your systems operate smoothly and securely. Order now for fast delivery and expert support.
Buy Mean Well SD200D12 now and experience unmatched reliability and performance with robust protections and high efficiency for your industrial power needs.
Frequently Asked Questions
Where can I buy MEAN WELL SD200D12?
You can click on the BUY or RFQ button to purchase SD200D12 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SD200D12?
You can download the SD200D12 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SD200D12?
MEAN WELL
