MEAN WELL SD200D48 High Power Industrial DC-DC Converter
The SD-200 series is a 200W single output DC-DC converter designed for industrial applications, offering a 2:1 wide input voltage range of 19-36V, 36-72V, or 72-144V. It features comprehensive protections against short circuits, overloads, over voltages, and temperature extremes, ensuring reliable operation. The converter provides 1500VAC isolation, operates with cooling via free air convection, and has passed full load burn-in tests for durability. Suitable for systems requiring high efficiency, stable voltage regulation, and robust safety standards, it is ideal for various automation and control equipment.
MEAN WELL SD200D48 High Power Industrial DC-DC Converter Specifications:
- Model: SD-200 series
- Input Voltage Range: 19~36VDC, 36~72VDC, 72~144VDC
- Output Power: 200W
- Output Voltages: 5V, 12V, 24V, 48V
- Rated Current: 40A (5V), 16.7A (12V), 8.4A (24V), 4.2A (48V)
- Ripple & Noise: Max. 100mVp-p to 200mVp-p depending on model
- Efficiency: Up to 86%
- Protections: Short circuit, Overload, Over voltage, Over temperature
- Isolation Voltage: 1500VAC
- Operating Temperature: -20°C to +60°C, with derating
- Storage Temperature: -40°C to +85°C
- Humidity: 20-90% non-condensing
- Dimensions: 215mm x 415mm x 50mm
- Safety Standards: UL60950-1, IEC60950-1, TUV CB approved for certain types
- MTBF: Minimum 218.2K hours
Buy the Mean Well Series SD: 200W High Power DC-DC Converter: SD-200D48
Purchase the Mean Well SD-200D48 online today to ensure reliable, efficient power conversion for your industrial equipment. This 200W converter provides a wide input range, strong protections, and excellent isolation for demanding applications. Designed for stability and durability, it features high efficiency up to 86%, comprehensive safety standards, and a rugged construction suitable for harsh environments. Ordering online guarantees quick delivery, trusted quality, and technical support to meet your power needs with confidence and performance you can depend on.
Get Mean Well SD-200D48 today—built for high efficiency and long-lasting durability in industrial power conversion.
Frequently Asked Questions
Where can I buy MEAN WELL SD200D48?
You can click on the BUY or RFQ button to purchase SD200D48 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SD200D48?
You can download the SD200D48 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SD200D48?
MEAN WELL
