MEAN WELL SPB09A05 DC-DC Converter
The SPBO9 and DPBO9 series are 9W isolated, regulated DC-DC converters in SIP8 packages, featuring high efficiency up to 89% and a wide temperature range of -40 to +90°C. They provide 1.5KVDC input-to-output isolation, continuous short circuit protection, and various input voltage options from 9V to 75V with multiple output voltages including 3.3V, 5V, 12V, 15V, and 24V. Suitable for industrial control, telecom, distributed power, and instrumentation, these modules ensure reliable performance across demanding environments.
MEAN WELL SPB09A05 DC-DC Converter Specifications:
- Input Voltage Range: 9~18V, 18~36V, 36~75V
- Output Voltages: 3.3V, 5V, 12V, 15V, 24V, +5V, +12V, +15V
- Output Current: 750mA to 2A depending on model
- Efficiency: Up to 89%
- Isolation Voltage: 1.5KVDC
- Operating Temperature: -40°C to +90°C
- Ripple & Noise: 100mVp-p
- Protection: Short circuit (continuous), overload (auto recovery), input under voltage
- Switching Frequency: Min. 400kHz
- Dimensions: 24*9.6*11.2mm
- Mounting: SIP8 package, industry standard pinout
- Certifications: EAC TP TC 004 approved
- Cooling: Free-air convection
- Storage Temp & Humidity: -40°C to +125°C, 10-95% RH non-condensing
Buy the Generic 9W – Reliable DC-DC Converter for Industrial Applications
Purchase the SPBO9 series 9W regulated DC-DC converters today online and ensure your projects benefit from high efficiency up to 89%, wide temperature operation, 1.5KVDC isolation, and reliable protection features. Suitable for industrial control, telecom, and instrumentation applications, these modules guarantee stable performance and easy integration in demanding environments. Secure your supply of high-quality power modules now and enjoy the convenience and speed of online ordering for your next project.
Order your industrial-grade SPB09 series 9W DC-DC converter today and enjoy dependable power conversion for telecom, control systems, and instrumentation projects.
Frequently Asked Questions
Where can I buy MEAN WELL SPB09A05?
You can click on the BUY or RFQ button to purchase SPB09A05 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SPB09A05?
You can download the SPB09A05 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SPB09A05?
MEAN WELL
