MEAN WELL SPB09B12 DC-DC Converter
The SPB09B12 is a 9W isolated and regulated DC-DC converter in SIP8 package, featuring 88% efficiency, wide temperature range -40 to +90°C, and 1.5KVDC input-output isolation. It is suitable for industrial control, telecommunication, and distributed power systems. With various input voltages and output options, it offers high reliability, short circuit protection, and remote ON/OFF control. Designed for seamless integration in demanding environments, it ensures stable power conversion with minimal noise and ripple, meeting safety standards and ensuring device protection.
MEAN WELL SPB09B12 DC-DC Converter Specifications:
- Input Voltage Range: 9~75Vdc (9~18V, 18~36V, 36~75V orders)
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V (single and dual outputs available)
- Efficiency: Up to 89%
- Isolation Voltage: 1.5KVDC (input-output)
- Operating Temperature: -40°C to +90°C
- Short Circuit Protection: Continuous, auto recovery
- Ripple & Noise: 100mVp-p
- Line Regulation: 0.5%
- Load Regulation: 0.5% (single), 0.5% (dual)
- Switching Frequency: 400KHz
- Protection: Overload (120%-250%), over-voltage, no minimum load required
- Remote ON/OFF Control: Yes, Logic Compatibility
- Case Material: UL 94V-0 rated plastic
- Dimensions: 24*9.6*11.2mm
- Soldering Temperature: Max 260°C for 1-3 sec.
- Vibration Resistance: 10-500Hz, 2G
Buy the Buy Mean Well DC-DC Converter Part Number SPB09B12 Online
Purchasing the SPB09B12 DC-DC converter online ensures you receive a high-quality, efficient power module suitable for industrial, telecommunication, and control applications. Its wide input voltage range, 89% efficiency, and 1.5KVDC isolation offer outstanding performance and safety. The device's compact SIP8 package simplifies integration, while features like remote ON/OFF, short circuit protection, and high temperature tolerance ensure durability and reliable operation in demanding environments. Order now for fast delivery and expert support on your power system needs.
Buy Mean Well SPB09B12 now and experience unmatched reliability and performance in industrial power supply solutions.
Frequently Asked Questions
Where can I buy MEAN WELL SPB09B12?
You can click on the BUY or RFQ button to purchase SPB09B12 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SPB09B12?
You can download the SPB09B12 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SPB09B12?
MEAN WELL
