MEAN WELL DDR30G12 Industrial Power Converter
The DDR-30G12 series is a compact 30W DIN Rail type DC-DC converter designed for industrial automation, control systems, and communication equipment. Featuring a 4:1 ultra wide input range of 18~75V, with high efficiency up to 91%, and an operating temperature of -40°C to +85°C, it ensures reliable performance in harsh environments. The converter provides adjustable output voltage, full protection including short circuit, overload, and overvoltage, and 4KVdc I/O isolation. Easy DIN rail mounting, compact size, and robust design make it ideal for factory automation and telecom applications.
MEAN WELL DDR30G12 Industrial Power Converter Specifications:
- Power Rating: 30W
- Input Voltage Range: 18~75Vdc
- Output Voltage Options: 5V, 12V, 15V, 24V
- Rated Current: 6A (for 5V), 2A (for 12V), 1.5A (for 15V), 1A (for 24V)
- Efficiency: Up to 91%
- Ripple & Noise: Max. 75mVp-p
- Line Regulation: ±0.5%
- Load Regulation: ±0.5%
- Adjustable Output Voltage: ±10%
- Operating Temperature: -40°C to +85°C
- Protection: Short circuit, Overload, Overvoltage, Reverse polarity
- Isolation: 4KVdc I/O
- Dimensions: 35mm(W) x 90mm(H) x 54.5mm(D)
- Mounting: TS-35/7.5 or 15 DIN rail
- MTBF: 483,300 hours (MIL-HDBK-217F at 25°C)
- Safety Standards: IEC 62968-1, UL508, CE
- Humidity: 5% to 95% RH non-condensing
- Vibration: 10-500Hz, 2G
Buy the Meanwell DDR-30G12 – Reliable Industrial DC-DC Converter for Automation
Purchase the Meanwell DDR-30G12 industrial power converter online today to ensure reliable, efficient power conversion for your control, communication, and automation systems. Designed for rugged environments, it offers ultra wide input, high efficiency, and full protection features including short circuit, overload, and overvoltage. Its compact size and DIN rail mounting make installation simple and adaptable in industrial settings. Trust this proven solution for factory automation, telecom infrastructure, and semiconductor fabrication applications. Order now for prompt delivery and continuous system performance.
Get Meanwell DDR-30G12 today—built for precision, high efficiency, and long-lasting durability in industrial automation and control systems.
