MEAN WELL SPB09C24 DC-DC Converter Module
The SPB09C24 is a 9W isolated, regulated DC-DC converter in a SIP8 package, offering wide input range options of 36~75V and high efficiency up to 89%. It features 1.5KVDC input-output isolation, operates reliably within -40 to +90°C, and includes protections for short circuits and overloads. Suitable for industrial control, telecom, distributed power, and instrumentation applications, this conversion module delivers stable output voltages like 24V, with low ripple noise and compact dimensions (24*9.6*11.2mm). It complies with safety standards and ensures long service life in demanding environments.
MEAN WELL SPB09C24 DC-DC Converter Module Specifications:
- Input voltage range: 36~75V
- Output voltage: 24V
- Rated power: 9W
- Input/output isolation voltage: 1.5KVDC
- Efficiency: up to 89%
- Operating temperature: -40°C to +90°C
- Ripple & noise: 100mVp-p
- Line regulation: 0.5%
- Load regulation: 0.5%
- Switching frequency: 400KHz
- Overload protection: 120~250% rated output power
- Short circuit protection: Continuous, automatic recovery
- Dimension: 24*9.6*11.2mm
- Case material: Non-conductive UL 94V-0 plastic
- Working humidity: 20% to 90% RH
- Storage temp: -40°C to +125°C
- Vibration: 10-500Hz, 2G
- Safety standard: EAC TP TC 004
Buy the Buy Mean Well DC-DC Converter Part Number SPB09C24 Online
Order the Mean Well SPB09C24 DC-DC converter today to ensure a reliable power supply for industrial, telecom, or instrumentation applications. Its high efficiency up to 89%, wide input voltage range, and compact SIP8 package make it perfect for space-constrained environments. The robust design features 1.5KVDC input-output isolation, automatic short circuit recovery, and operating temperatures from -40°C to +90°C. Purchase online now to benefit from fast shipping, competitive pricing, and proven quality for your demanding projects.
Get Mean Well SPB09C24 today—compact, high-efficiency power conversion module built for industrial reliability and long-lasting performance.
Frequently Asked Questions
Where can I buy MEAN WELL SPB09C24?
You can click on the BUY or RFQ button to purchase SPB09C24 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SPB09C24?
You can download the SPB09C24 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SPB09C24?
MEAN WELL
