MOLEX 09508030 Crimp Terminal
This high-quality crimp terminal connector is crafted from UL94V-0 glass-filled polyester, ensuring flame resistance and durability. Designed for reliable electrical connections, it accommodates various wire sizes with max insulation diameters ranging from 0.065 to 0.110 inches. Suitable for 2-14 circuit applications, it features precise dimensions and compatibility with standard headers and round or square pins. The terminal's molded natural finish and optional ramps aid in installation and polarization, making it ideal for industrial and electronic assembly requiring robust, dependable terminal connections.
MOLEX 09508030 Crimp Terminal Specifications:
- Material: N-Glass Filled Polyester, UL94V-0 Molded Natural
- Number of Circuits: 2-14
- Dimensions: Length varies with option, typical 4.0 mm to 16.71 mm, Width from 1.14 mm to 7.92 mm
- Wire Range: 18-26 AWG, with insulation maximum diameters from 0.065 to 0.110 inches
- Finish: See terminal drawings, optional ramps for polarizing ribs
- Compatibility: Mates with 18-24 AWG headers, square and round pins, with optional polarized or breakaway features
- Certifications: UL Listed, CSA Certified
- Additional Notes: Designed for reliable, high-volume electronic and industrial applications including wiring harnesses and control panels.
Buy the Buy Molex Crimp Terminal Part Number 09508030 Online
Secure your electrical connections efficiently with the Molex crimp terminal. Crafted from UL94V-0 glass-filled polyester, it ensures flame resistance and durability. Suitable for 2-14 circuit wiring requiring precise dimensions and compatibility with standard headers and pins. Easy to install with optional ramps and polarization features, making it ideal for control panels, wiring harnesses, and electronic assemblies. Purchase online today to receive fast delivery, reliable quality, and support for industrial and electronic projects requiring robust, high-quality terminal connections.
Order your Molex Series09508030 crimp terminal today and ensure dependable, secure electrical connections in your projects with high durability and precision.
Frequently Asked Questions
Where can I buy MOLEX 09508030?
You can click on the BUY or RFQ button to purchase 09508030 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 09508030?
You can download the 09508030 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 09508030?
MOLEX
