MOLEX 1053131105 Nano-Fit Header
The MOLEX 105313-1105 Nano-Fit Right-Angle Header is a compact and reliable connector solution for wire-to-board applications. Designed with a 2.50mm pitch and 5 circuits, this header offers a secure and efficient connection. Its right-angle orientation simplifies PCB layout and reduces space requirements. The tin plating ensures excellent solderability and corrosion resistance, while the liquid crystal polymer resin provides durability and heat resistance. Ideal for applications in consumer electronics, automotive systems, and industrial equipment, the 105313-1105 provides a robust and space-saving connection option.
MOLEX 1053131105 Nano-Fit Header Specifications:
- Part Number: 1053131105
- Status: Active
- Overview: Nano-Fit Power Connectors
- Description: Nano-Fit Right-Angle Header, Through Hole, 2.50mm Pitch, Single Row, 5 Circuits, Tin (Sn) Plating, Black, Glow-Wire Capable, Tray
- Circuits (Loaded): 5
- Circuits (maximum): 5
- Color - Resin: Black
- Durability (mating cycles max): 25
- Flammability: 94V-0
- Glow-Wire Capable: Yes
- Guide to Mating Part: Yes
- Lock to Mating Part: Yes
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Liquid Crystal Polymer
- Net Weight: 0.630/g
- Number of Rows: 1
- Orientation: Right Angle
- PC Tail Length: 3.20mm
- PCB Locator: Yes
- PCB Retention: Yes
- PCB Thickness - Recommended: 1.60mm, 2.40mm
- Packaging Type: Tray
- Pitch - Mating Interface: 2.50mm
- Pitch - Termination Interface: 2.50mm
- Plating min - Mating: 1.524µm
- Plating min - Termination: 1.524µm
- Polarized to Mating Part: Yes
- Polarized to PCB: Yes
- Stackable: No
- Surface Mount Compatible (SMC): No
- Temperature Range - Operating: -40° to +105°C
- Termination Interface Style: Through Hole
- Current - Maximum per Contact: 8.0A
- Voltage - Maximum: 250V AC (RMS)/DC
