MOLEX 10897361 PCB Connector
The 2.54mm Pitch C-Grid Breakaway Header is a high-temperature, dual-row, vertical PCB connector designed for board-to-board and wire-to-board applications. Featuring 36 circuits with tin plating and a 2.72mm PC tail length, it offers reliable electrical performance at 3.0A and 250V. Made from high-temperature thermoplastic with copper alloy contacts, this shrouded, stackable connector supports up to 50 mating cycles and operates from -40°C to +105°C. Its RoHS and UL certifications ensure safety and eco-friendliness for industrial and electronic manufacturing use.
MOLEX 10897361 PCB Connector Specifications:
- Pitch: 2.54mm
- Number of Circuits: 36
- Current per Contact: 3.0A
- Voltage: 250V
- Material - Mating: Copper Alloy
- Plating - Mating & Termination: Tin
- Material - Resin: High-Temperature Thermoplastic
- Color - Resin: Not specified
- PC Tail Length: 2.72mm
- Operating Temperature Range: -40°C to +105°C
- Durability (Mating Cycles): Up to 50 cycles
- Stackable: Yes
- Shrouded: Yes
- RoHS & UL Certification: Yes
- Solder Process: Wave, 245°C maximum temperature
- Net Weight: Approximate, not specified
Buy the Molex 0010897361 – Reliable Signal Connector for Industrial Applications
Secure your electronic projects with the Molex PCB Connector featuring a 2.54mm pitch and 36 circuits. Designed for industrial applications, it delivers excellent electrical performance and durability with UL and RoHS compliance. Easy to install, stackable, and capable of withstanding up to 50 mating cycles, this high-temperature thermoplastic connector ensures stable, reliable connections in demanding environments. Perfect for board-to-board or wire-to-board configurations, it’s the ideal component for professionals seeking quality and safety in electronic assembly.
Buy Molex 0010897361 now and experience unmatched reliability and performance in high-temperature PCB connections.
Frequently Asked Questions
Where can I buy MOLEX 10897361?
You can click on the BUY or RFQ button to purchase 10897361 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 10897361?
You can download the 10897361 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 10897361?
MOLEX
