MOLEX 10897802 C-Grid Connector
This high-temperature, 2.54mm pitch C-Grid connector features a dual row, vertical orientation, and includes 80 circuits with gold and tin plating for reliable electrical performance. Designed for board-to-board applications, it supports up to 3.0A current per contact and a maximum voltage of 250V. Constructed from high-quality copper alloy and thermoplastic, it offers durability with up to 10 mating cycles, suited for industrial and electronic instrument use. The connector withstands operating temperatures from -40°C to +105°C, ensuring functionality in harsh environments.
MOLEX 10897802 C-Grid Connector Specifications:
- Pitch: 2.54mm
- Number of Rows: 2
- Circuits (Loaded): 80
- Maximum Circuits: 80
- Material - Metal: Copper Alloy
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Color - Resin: Not specified
- Operating Temperature Range: -40°C to +105°C
- Current per Contact: 3.0A
- Voltage Maximum: 250V
- PC Tail Length: 2.79mm
- PCB Thickness - Recommended: 1.60mm
- Durability (Mating Cycles Max): 10
- Lock to Mating Part: No
- Shrouded: No
- Stackable: No
- Terminal Interface Style: Through Hole
- Flammability: UL 94V-0
- Certifications: CSA, UL
- Process Capability: Lead-free, SMC & WAVE soldering
Buy the Molex 10897802 – Reliable C-Grid Connectors for Industrial Applications
Discover the Molex 10897802 C-Grid connector, engineered for high-temperature, high-reliability applications. Featuring 80 circuits with gold and tin plating, it provides exceptional electrical performance for board-to-board connections. Its durable construction withstands -40°C to +105°C temperatures, making it ideal for industrial and military electronics. Easy to integrate with through-hole termination, it supports up to 3A current per contact and 250V voltage. Purchase this reliable connector online today and ensure your next project benefits from top-quality, long-lasting performance.
Buy Molex 10897802 high-temperature C-Grid connector now and experience reliable performance and robust electrical connection in industrial environments.
Frequently Asked Questions
Where can I buy MOLEX 10897802?
You can click on the BUY or RFQ button to purchase 10897802 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 10897802?
You can download the 10897802 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 10897802?
MOLEX
